Instructions
Laser AdBlue Dispenser
LA 30S
LLA 30S (AdBlue duo)
LLA 30S (AdBlue duo - nozzles on same end)
LLA 30-40S (AdBlue & diesel duo)
LA 30-40SD (AdBlue & diesel lane specific)
LLA 30-40SQ (AdBlue & diesel quad)
LLA 30-80S (AdBlue & diesel duo)
LA 30-80SD (AdBlue & diesel lane specific)
LLA 30-80SQ (AdBlue & diesel quad)
LLA 30-160S (AdBlue & diesel duo)
LA 30-160SD (AdBlue & diesel lane specific)
LLA 30-160SQ (AdBlue & diesel quad)
13 November 2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Compac Laser AdBlue LA 30S
Summary of Contents for Compac Laser AdBlue LA 30S
- Page 1 LLA 30-160SQ (AdBlue & diesel quad) Date of issue: 13 November 2014 Compac Industries Ltd. 52 Walls Road. Penrose. Auckland 1061. New Zealand. PO Box 12 417. Penrose. Auckland 1642. New Zealand. Tel: +64 9 579 2094 Fax: +64 9 579 0635 info@compac.co.nz www.compac.co.nz...
-
Page 2: Table Of Contents
Contents Contents ............................2 Conditions of use ........................3 Static Electricity Precautions .....................4 Pre-installation Check ......................4 AdBlue pump specifications ......................4 Electrical requirements ......................4 Installation ..........................5 Footprints ..........................6 LLA 30S (two hose with nozzles on opposite ends) ..............6 LLA 30S Duo (two hose with nozzles on same end) ...............7 LA 30S .........................8 LA30-40SD LA30-80SD LLA30-40S LLA30-80S ..............9 LA 30-160SD LLA 30-160S ................... -
Page 3: Conditions Of Use
Unless otherwise noted, references to brand names, product names, or trademarks constitute the intellectual property of the owner thereof. Subject to your right to use the unit, Compac does not convey any right, title, or interest in its intellectual property, including and without limitation, its patents, copyrights, and know-how. -
Page 4: Static Electricity Precautions
This is not a recommended alternative to wearing an anti-static wrist strap. Note: Compac Industries Limited reserves the right to refuse to accept any circuit boards returned, if proper anti-static precautions have not been taken. -
Page 5: Installation
Installation Installation should be in accordance with local regulations. The dispensing equipment shall be installed to prevent the delivery hose from contacting the ground when not in use. Dispensers should be mounted on a solid, level surface and secured using the fastening holes as shown in the footprint drawings. -
Page 6: Footprints
Footprints LLA 30S (two hose with nozzles on opposite ends) G:\Masters\Installation Sheets\AdBlue\AdBlue Laser Installation Sheet.doc Page 6 of 23... -
Page 7: Lla 30S Duo (Two Hose With Nozzles On Same End)
LLA 30S Duo (two hose with nozzles on same end) G:\Masters\Installation Sheets\AdBlue\AdBlue Laser Installation Sheet.doc Page 7 of 23... -
Page 8: La 30S
LA 30S G:\Masters\Installation Sheets\AdBlue\AdBlue Laser Installation Sheet.doc Page 8 of 23... -
Page 9: La30-40Sd La30-80Sd Lla30-40S Lla30-80S
LA30-40SD LA30-80SD LLA30-40S LLA30-80S G:\Masters\Installation Sheets\AdBlue\AdBlue Laser Installation Sheet.doc Page 9 of 23... -
Page 10: La 30-160Sd Lla 30-160S
LA 30-160SD LLA 30-160S G:\Masters\Installation Sheets\AdBlue\AdBlue Laser Installation Sheet.doc Page 10 of 23... -
Page 11: Lla 30-40Sq Lla30-80Sq Lla30-160Sq
LLA 30-40SQ LLA30-80SQ LLA30-160SQ G:\Masters\Installation Sheets\AdBlue\AdBlue Laser Installation Sheet.doc Page 11 of 23... -
Page 12: Electrical Connections
Electrical Connections Electrical cables are terminated at the C4000 Power Supply, which is housed in the Flameproof Enclosure located in the bottom of the dispenser, behind the door The incoming cables are terminated as shown in the following picture. Note: Output to pump(s) goes to the pump contactor, not directly to the pump wiring. G:\Masters\Installation Sheets\AdBlue\AdBlue Laser Installation Sheet.doc Page 12 of 23... -
Page 13: Dispensing Hoses And Nozzles
Dispensing Hoses and Nozzles The unit may or may not be supplied with dispensing hose and nozzle assemblies. If customer supplied hose assemblies, pylons, reels, safe breaks and nozzles are used they must comply with the requirements outlined in AS/NZS 2229 All hoses, nozzles and fittings that come in contact with AdBlue must be compatible with it. -
Page 14: Electrical Operation Test
Electrical Operation Test An encoder dummy plug (Part number F-CU-ENC-ABL-PT) is required to avoid getting error messages during the electrical operation test of the AdBlue side of the dispenser. Make sure that the inlet shut-off valves are closed (these are the valves in the inlet lines at the base of the dispenser, but they are not part of the dispenser). -
Page 15: Mechanical Commissioning And Air Purge
Configuration Code 14.1 The configuration code has been set at Compac and should not be changed In the event of it being lost and having to be re-entered the configuration is written on the yellow label on the C4000 processor board cover. -
Page 16: Parameter Switch Settings
2. Continue to press the K factor switch until the number to be changed flashes. Hold the switch down and this number will then increment. 3. Release the switch when the required number is displayed. The value of the displayed number will then be stored in the C4000 memory as the Submersible Delay. -
Page 17: K-Factor Switch Settings
K-Factor Switch Settings 14.4 K-Factor, and other various configuration settings, are set via this switch. The position of the K- Factor switch is shown in the diagram below: Parameter Switch K factor K Factor Switch Switch Parameter Switch Connections for Single and Duo dispensers J1: Comms Test J7: Displays J13: Not used... -
Page 18: Calibration (K-Factor)
Calibration (K-Factor) Setting the K-Factor 15.1 K-Factor is a proportional calibration factor of litres dispensed per revolution of the meter. To calibrate the dispenser, dispense AdBlue (and fuel if a dual dispenser) into a certified measuring container, and compare the display value with the amount dispensed. Example: Display shows 10.00 True volume... -
Page 19: Standalone Operation
Standalone Operation In standalone operation, the dispenser will continue working when not connected to a controller. 'Stand-alone' mode being when no authorisation of fills is required and so fills are simply initiated by removing the refuelling assembly from its holder. If standalone operation is inhibited, the dispenser will not work in 'stand-alone' mode, regardless of whether the dispenser is ON LINE to a controller or not. -
Page 20: Zva Adblue Nozzle
ZVA AdBlue Nozzle 18.2 The ZVA AdBlue nozzle with a magnetic safety catch is commonly used on AdBlue dispensers. The following image is included for reference. For further information refer to ZVA direct. G:\Masters\Installation Sheets\AdBlue\AdBlue Laser Installation Sheet.doc Page 20 of 23... -
Page 21: Error Messages
Error Messages Error Code Fault Action Err 3 No price or pump number set. Set the pump number or: Set a price at the pump or at the controller. Err 7 Excess flow. Max Flowrate exceeded Err 8 Excess reverse rotation of encoder. Check product is not flowing back into the tank once the delivery has finished. -
Page 22: Product Details
Product Details Fill in the product details and service agent contact details. Use this information when contacting service agent or help desk. Model number Serial number Date of manufacture Date of installation Software version Equipment connected to the unit Phone number (if dial in site) Merchant ID number (Eftpos site) Contact Details Service Agent... -
Page 23: Manufacturer Contact Details
Manufacturer Contact Details Manufacturer Contact The Compac AdBlue Dispenser is designed and Details manufactured by: Compac Industries Limited 52 Walls Road, Penrose, Auckland 1061, New Zealand P.O. Box 12-417, Penrose, Auckland 1641, New Zealand Phone: + 64 9 579 2094 Fax: + 64 9 579 0635 www.compac.co.nz...
