Unless otherwise noted, references to brand names, product names, or trademarks constitute the intellectual property of the owner thereof. Subject to your right to use the unit, Compac does not convey any right, title, or interest in its intellectual property, including and without limitation, its patents, copyrights, and know-how.
This is not a recommended alternative to wearing an anti-static wrist strap. Note: Compac Industries Limited reserves the right to refuse to accept any circuit boards returned, if proper anti-static precautions have not been taken.
Page 7
MUST be used so that the inlet of the pump cannot become pressurised at any time. The air switch is not to be disconnected. Disconnection will void NSC and TMU approvals. \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR160P Installation Sheet.doc Page 7 of 18...
C4000 Power Supply or incorrect operation of the triacs. These switches are set in the factory and should not be changed. If they are accidentally changed these are the correct settings for Master / Premier Pump applications.Note: They are 3 position switches...
Note: Pump comm’s connect to pump controller such as DCA, Communicator Controller etc. (option). When replacing the lid of the flameproof enclosure, ensure the sealing O ring is in place. COMMS INCOMING MAINS + ve Neutral - ve Phase Earth \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR160P Installation Sheet.doc Page 9 of 18...
Configuration Codes 10.1 The configuration code has been set at Compac and should not be changed In the event of it being lost and having to be re-entered the configuration is written on the yellow label on the C4000 processor board cover Parameter Switch Settings 10.2...
Page 11
The price for side ‘B’ is shown as ‘PX.XXX’ on the times in quick succession litres display and ‘Prb’ is displayed on the money display. Repeat steps 3 to 5 above. \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR160P Installation Sheet.doc Page 11 of 18...
J15: Not used Side A J4: Input from KG Meter J10: Totes J16: Not used Side B J5 : Not Used J11: Buzzer J17 Backlighting J6 Not used J12 Nozzle Switches \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR160P Installation Sheet.doc Page 12 of 18...
Factor 10.00 Existing Factor Change the existing 'K' Factor to this new value. Sealing the K-Factor switch 11.2 After calibration the K-factor switch should be sealed as shown \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR160P Installation Sheet.doc Page 13 of 18...
3) For units where the generator starts and stops on demand, install a delay timer or PLC to automatically isolate the unit until the operating speed and consistent power output is achieved. 4) Isolate the unit before shutting down the generator. \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR160P Installation Sheet.doc Page 14 of 18...
(incl inlet and outlet gaskets) C4000 power supply (does not include box) F-CP-C4PWR-ASSEM Motor triac F-AT-BTA40-RD91 Also not shown Track 2 cardreader F-BA-CARD-T2C4M Preset (Fascia c/w keypad and interface PCB) F-FAS-PSET-MEM \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR160P Installation Sheet.doc Page 16 of 18...
Added sump info in accordance with EPA. File ref. COM 09 29 Added flange and flexi coupling detail. 27 August 2014 Added front page footer, added outlet size. 13 September 2014 Added outlet height dimension \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR160P Installation Sheet.doc Page 18 of 18...
