Installation and Setup
Model:
Versions: MR40S
Date of issue:
Compac Industries Ltd.
52 Walls Road. Penrose. Auckland 1061. New Zealand.
PO Box 12 417. Penrose. Auckland 1642. New Zealand.
Tel: +64 9 579 2094 Fax: +64 9 579 0635
www.compac.co.nz
Instructions
Master
MR80S
27 January 2015
info@compac.co.nz
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Compac Master MR40S
Summary of Contents for Compac Master MR40S
- Page 1 Versions: MR40S MR80S Date of issue: 27 January 2015 Compac Industries Ltd. 52 Walls Road. Penrose. Auckland 1061. New Zealand. PO Box 12 417. Penrose. Auckland 1642. New Zealand. Tel: +64 9 579 2094 Fax: +64 9 579 0635 info@compac.co.nz...
-
Page 2: Table Of Contents
Contents Conditions of use ........................3 Footprint ..........................4 Optional Flexi Coupling ....................5 Static Electricity Precautions .....................6 Pre-installation Check ......................6 Installation ..........................6 Comms Dip-switch settings ......................6 Standard Pump Comms Setting ..................6 Gilbarco Pump comms Setting ..................7 Triac Dip-switches ........................7 Electrical Connections ......................8 Submersible Pump connections ..................8 Dispensing Hoses and Nozzles ....................9 Breakaways ........................9... -
Page 3: Conditions Of Use
Unless otherwise noted, references to brand names, product names, or trademarks constitute the intellectual property of the owner thereof. Subject to your right to use the unit, Compac does not convey any right, title, or interest in its intellectual property, including and without limitation, its patents, copyrights, and know-how. -
Page 4: Footprint
Footprint Outlets are approximately 680mm above the base: 40 l/min ¾” female BSP socket 80 l/min 1” female BSP socket Note: This drawing does not apply to Aviation dispensers (stainless steel pipework) \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR40S MR80S Installation Sheet.doc Page 4 of 17... -
Page 5: Optional Flexi Coupling
Optional Flexi Coupling \\Cilaklfs1\shrdata\Masters\Installation Sheets\Master & Premier\MR40S MR80S Installation Sheet.doc Page 5 of 17... -
Page 6: Static Electricity Precautions
This is not a recommended alternative to wearing an anti-static wrist strap. Note: Compac Industries Limited reserves the right to refuse to accept any circuit boards returned, if proper anti-static precautions have not been taken. -
Page 7: Gilbarco Pump Comms Setting
Gilbarco Pump comms Setting (Special software and interface board required) 1-OFF 2-ON 3-OFF 4-ON Triac Dip-switches Important note: Great care should be taken not to accidentally change the setting of these switches while working in the Flame-proof box. Operating the unit with these incorrectly set can result in damage to the C4000 Power Supply or incorrect operation of the triacs. -
Page 8: Electrical Connections
Electrical Connections Prior to pump installation ensure that there is at least a two-metre tail on the incoming underground mains supply / pump contactor cable and comms cable (if comms enabled). These cables are terminated at the C4000 power supply, which is housed in the flameproof enclosure located in the bottom of the pump, behind the door. -
Page 9: Dispensing Hoses And Nozzles
Configuration Codes 10.1 The configuration code has been set at Compac and should not be changed In the event of it being lost and having to be re-entered the configuration is written on the yellow label on the C4000 processor board cover Submersible Delay (Sd) 10.2... -
Page 10: Parameter Switch Settings
Parameter Switch Settings 10.3 10.3.1 Setting the Pump Number This must be set at the pump, for each hose, so that communications with a controller can take place. The location of this switch is shown in the diagram below. Depress the Parameter Switch nine (9) or more times until the message 'PnA XX' appears in the litres display window. -
Page 11: K-Factor Switch Settings
K-Factor Switch Settings 10.4 K-Factor, and other various configuration settings, are set via this switch. The position of the K- Factor switch is shown in the diagram below: Parameter Switch K factor K Factor Switch Switch Parameter Switch J1: Comms Test J7: Displays J13: Not used J2: To Power Supply... -
Page 12: Calibration (K-Factor)
Calibration (K-Factor) Setting the K-Factor 11.1 K-Factor is a proportional calibration factor of litres dispensed per revolution of the meter. To calibrate the dispenser/pump, dispense fuel into a certified measuring container, and compare the display value with the amount dispensed. Example: Display shows 10.00 True volume... -
Page 13: Standalone Operation
Standalone Operation 11.3 In standalone operation, the dispenser will continue working when not connected to a controller. 'Stand-alone' mode being when no authorisation of fills is required and so fills are simply initiated by removing the refuelling assembly from its holder. If standalone operation is inhibited, the dispenser will not work in 'stand-alone' mode, regardless of whether the dispenser is ON LINE to a controller or not. -
Page 14: Error Messages
Error Messages Error Code Fault Action Err 3 No price or pump number set. Set the pump number or: Set a price at the pump or at the controller. Err 7 Excess flow. Max Flowrate exceeded Err 8 Excess reverse rotation of encoder. Check product is not flowing back into the tank once the delivery has finished. -
Page 15: Mr40S Mr80S Spare Parts
MR40S MR80S Spare Parts Commercial Display (as shown - includes backlighting) F-CP-DISPLAY-CMH Retail display (includes backlighting) F-CP-DISPLAY-GD1H Tote F-BA-TOTE-A-K C4000 Microprocessor Board F-CP-C4PROCES-A Nozzle Holder F-NOZL-HLDR-ME5SR Solenoid (complete) F-SOLND-S20-2P1X COM50 Meter (complete) F-METER-COM50 WPE2 COM50 Meter (electronics only) F-METER-COM50ESP2 Filter Element F-FILTER-921999 (40 lpm only) F-FILTER-926169 (80 lpm only) C4000 Power Supply... -
Page 16: Product Details
Phone E-mail Address 1 Address 2 Notes Manufacturer Contact The Compac Master Dispenser is designed and Details manufactured by: Compac Industries Limited 52 Walls Road, Penrose, Auckland 1061, New Zealand P.O. Box 12-417, Penrose, Auckland 1641, New Zealand Phone: + 64 9 579 2094 Fax: + 64 9 579 0635 www.compac.co.nz... -
Page 17: Revision History
Revision History Previous revision date Summary of changes 25 May 2009 Added contact details and revision history, updated spare parts 16 June 2011 Added installation text. Added Conditions of Use, generator precautions, breakaway info, 06 June 2012 new C4000 wiring Updated electrical connections.
