Main Dispenser Parts

Dispenser spare parts

Main Dispenser Parts
Main Dispenser Spare Parts
See diagram on the next page for parts location.
Item Part Number
A F-CP-DSPLAY-GD1H
F-CP-DSPLAY-GD2H
F-BA-TOTE-A-K
F-CP-PRESET-3KMB
F-CP-PRESET-3KMV
B FC-GAUGE-0001
FC-GAUGE-0003
FC-GAUGE-0005
FC-GAUGE-0006
C FC-VALVE-0001
FC-SK-0010
FC-B8-HLDBLK
FC-B8-HDLRED
FC-B8-HLDGSCR-SS
D F-CP-PROCES-A
F-AD-DS1225
F-CS-IC-C4DISP
E F-CP-C4PWR-ASSEM
F-C4PWR-FUSEKIT
F-CP-C4GILB-I/F-K
F FC-PBSW-ESTOP
FC-PBSW-START
G F-D-METER-KG80T
H Compac Hydraulic Module
Compac Industries Ltd.
The following lists contain the most commonly used spare parts
and kits for Servicing Compac Dispensers. They are not an
exhaustive list of all possible parts for current or historical
Dispensers. If a part you want to order is not listed, please contact
the Compac spare parts department for a complete listing.
GD1 Display With One Unit Price LCD (CI170)
GD1 Display With Two Unit Price LCDs (CI170)
Electromechanical Tote With 200mm Cable
3 Key Membrane Keypad - Horizontal
3 Key Membrane Keypad - Vertical
Dual Scale Pressure Gauge, Units Of Measure In "bar + psi" 100mm. Used on
units up to serial number 07F-XXXXXX July 07
Dual Scale Pressure Gauge, Units Of Measure In "bar + psi" 100mm. Used on
units from serial number 07g-XXXXXX July 07 onwards
Dual Scale Pressure Gauge, Units Of Measure In "kg/cm2 + psi" 100mm
Dual Scale Pressure Gauge, Units Of Measure In "Mpa + psi" 100mm
Isolating Valve (Complete). Parker 2 Way 8 Series Stainless Steel
Isolating Valve Seal Kit, Parker 2 Way 8 Series
Isolating Valve Handle (Black), Parker 2 Way 8 Series
Isolating Valve Handle (Red), Parker 2 Way 8 Series
Isolating Valve Handle Grub Screw, Parker 2 Way 8 Series
C4000 Processor Board, No Memory Or Software (CI140)
Dallas Memory Chip
Software Chip (Please Specify Code Version Required When Ordering)
C4000 Power Supply (CI138/139)
C4000 Power Supply Fuse Kit
Gilbarco Interface Board Kit For C4000 Power Supply
Red Stop Button With Mushroom Head
Green Start Button
KG80 Mass Flow Meter
Please See Hydraulic Module Spare Parts
Page 116
