Hydraulic Module Parts - Compac CNG Service Manual

Dispenser spare parts

Hydraulic Module Parts

Item Part Number
A FC-COIL-0001
FC-COIL-0005
B FC-VALVE-0035
FC-VALVE-0036
FC-VALVE-0037
FC-SK-0001
FC-VALVE-PSTN-0001
FC-VALVE-PSTN-S2
FC-SVK-0001
FC-SVK-0003
FC-SVK-0004
FC-VALVE-0018
C FC-FIL-0001
FC-VALVE-0012
D FC-SK-0005
E FC-SK-0002
FC-VALVE-0015
There are two different solenoid valves available, rated for either 275 or 350 bar pressure. Always quote
the serial number of your dispenser when ordering parts, check the part you receive matches the model number on the
valve label and never replace valves with a different type.
Compac Industries Ltd.
Description
SCI-12-SS solenoid coil (Parker) With 3 metre lead
S2 -350 solenoid coil (Compac) with 3 metre lead
S2-350 Complete 350 bar standard solenoid (Without Coil )
S2-350 Complete 350 bar solenoid with O ring piston (Without Coil )
S2-350 Complete 350 bar low temperature solenoid (Without Coil )
Solenoid Seal Kit for all valves
Solenoid Piston - standard
Solenoid Piston (O ring style for high oil content gasses)
SCI-12-SS Solenoid Top Service Kit (275 bar models only)
S2-350 Solenoid Top Service Kit (350 bar standard)
S2-350 Solenoid Top Service Kit (350 bar low temperature)
SCI-12-SS Complete 275 bar solenoid (Without Coil )
FCVCI-12-SS Grade 10 Coalescing Filter Element And Filter Bowl O-ring
FCVCI-12-SS Complete Filter/Check Valve With Grade 10 Coalescing Filters
FCVCI-12-SS Check Valve Seal Kit
RCI-12-SS Regulator Valve Seal Kit
RCI-12-SS Complete Regulator Valve
Page 119
