GeoVision VS04H Quick Start Manual page 7

No. Name
1 Video Input
2 Speaker Output
3 Audio Input
4 Default Button
5 Disk Full/Fault LED
6 Ready LED
7 Power LED
8 Reset
9 USB Port
10 Terminal Block
11 Ethernet Port
12 Power Out
13 Power In
Function
4 plugs for video inputs.
A plug for the speaker device.
Each plug is for 2 audio inputs.
It resets all configurations to their factory
settings. See 7 Restoring to Default Settings in
the Quick Start Guide.
This LED is on, indicating the hard drive is full
or faulty.
This LED is on, indicating the GV-Video Server
is ready for connection.
This LED is on, indicating the power is
supplied.
It reboots the GV-Video Server, and keeps all
current configurations.
2 USB ports for installing portable storage
devices.
The connectors for digital input, relay output,
PTZ camera, Wiegand device and GPS module
control.
A plug for a 10/100 Ethernet or PoE.
Note: GV-VS14 does not support PoE function.
A plug to power on the camera, by using a DC
Male-to-Male Cable, directly through the
GV-Video Server.
Note: When PoE is applied, you cannot power
on the camera through the GV-Video Server.
A plug to power on the GV-Video Server.
