Quick Start Guide

GV-Video Server
Thank you for purchasing GV-Video Server. This guide is designed to assist the new user
in getting immediate results from the GV-Video Server. For advanced information on how to
use the GV-Video Server, please refer to GV-Video Server User's Manual on Software
2016/11
DVD.
English
© 2016 GeoVision Inc. All rights reserved.
VS2420-2400-QG-B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS04H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision VS04H

Summary of Contents for GeoVision VS04H

  • Page 1: Quick Start Guide

    Thank you for purchasing GV-Video Server. This guide is designed to assist the new user in getting immediate results from the GV-Video Server. For advanced information on how to use the GV-Video Server, please refer to GV-Video Server User's Manual on Software 2016/11 DVD. English © 2016 GeoVision Inc. All rights reserved. VS2420-2400-QG-B...

  • Page 2: Packing List

    Welcome to the GV-Video Server Quick Start Guide. In the following sections, you will learn about the basic installations and configurations of the GV-Video Server (VS04H / VS11 / VS12 / VS14 / VS2420 / VS2400). For a detailed user’s manual, see GV-Video Server User’s Manual on the GV-Video Server software CD/DVD.
  • Page 3 GV-VS11 ● GV-VS11 ● Power Adaptor x 1 ● GV-Video Server Software CD/DVD x 1 ● GV- NVR Software CD/DVD x 1 GV-VS12 ● GV-VS12 ● I/O Cable with RJ-45 Connector x 1 ● Sticker (for positioning conical anchors) x 1 ●...
  • Page 4 GV-Compact DVR, to the wireless network. GV-PA191 PoE Adaptor The GV-PA191 is designed to provide power to the IP device through a single Ethernet cable. The GV-PA191 is only supported by GV-VS04H, and GV-VS12. GV-VR605A DC Voltage With the GV-VR605A, you can install GV-Video Regulator Server in the car.
  • Page 5 The GV-Video Server can work with the Wiegand-interface card reader to send cardholder data to the central monitoring stations Center V2 and VSM, as well as GV-System (GV-DVR / NVR). The following devices are only supported by GV-VS04H and GV-VS14. GV-Reader GV-Reader includes transmit-receive antenna and electronics.
  • Page 6 Overview GV-VS04H / GV-VS14 Front View 3 4 5 6 7 8 3 4 5 6 7 8 Rear View...
  • Page 7 Name Function Video Input 4 plugs for video inputs. Speaker Output A plug for the speaker device. Audio Input Each plug is for 2 audio inputs. Default Button It resets all configurations to their factory settings. See 7 Restoring to Default Settings in the Quick Start Guide.
  • Page 8 GV-VS11 Front View Rear View Name Function Video Input 1 plug for video input. Default Button It resets all configurations to their factory settings. See 7 Restoring to Default Settings in the Quick Start Guide. Audio Input 1 plug for audio input. Ready LED This LED is on, indicating the GV-Video Server is ready for connection.
  • Page 9 GV-VS12 Front View Rear View 10 11 12...
  • Page 10 Name Function USB Port 1 USB port for installing the portable storage device. Speaker Output A plug for the speaker device. Audio Input 2 plugs for audio inputs. Video Input 2 plugs for video inputs. Power In A plug to power on the GV-Video Server. Ethernet Port A plug for inserting an Ethernet cable to build the network connection.
  • Page 11 GV-VS2420 / 2400 Front View Rear View 12 13 Name Function Video Input 4 plugs for video inputs. Line Out A plug for Video 1 speaker device. Line In A plug for Video 1 audio input. Reset It reboots the GV-Video Server, and keeps all current configurations.
  • Page 12 Power LED This LED is on, indicating the power is supplied. USB Port 2 USB ports for installing portable storage devices. The connectors for digital input, relay output, Terminal Block and PTZ camera. See Chapter 9 Auxiliary Device Connectors. Gigabit Ethernet A plug for a 10/100/1000 Base-T Ethernet Port Power Out...

  • Page 13: Installing On A Network

    Installing on a Network Here we use GV-VS04H as an example to demonstrate the basic connections. 1. Connect your camera’s video output to the BNC video input. 2. Connect the microphone to the RCA audio input using the 3.5 mm Stereo to RCA Cable.
  • Page 14 1. The GV-VS11 / 14 and GV-VS2420 / 2400 do not support PoE function. 2. The DC Male-to-Male Cable and 3.5 mm Stereo to RCA Cable are only supplied for GV-VS04H and GV-VS14. Optionally purchase these accessories for GV-VS2420 / 2400.

  • Page 15: System Requirements

    System Requirements To access the Web interface of the GV-Video Server, ensure your PC is in goodnetwork connection and use one of the following Web browsers: For GV-VS04H and GV-VS11 / 12 / 14 ● Microsoft Internet Explorer 7.x or later For GV-VS2420 / 2400 ●...
  • Page 16 Checking the IP Address and Logging In By default, the IP address of your GV-Video Sever is assigned by the DHCP server unless your router does not support DHCP. In this case, the default IP address will be 192.168.0.10. Follow the steps below to look up the IP address and access the Web interface.
  • Page 17 Note: If your router does not support DHCP, the default IP address will be 192.168.0.10. In this case, it is strongly suggested to modify the IP address to avoid IP address conflict with other GeoVision IP device on the same LAN. For details, see 2.3 Changing the IP Address, GV-Video...

  • Page 18: The Web Interface

    The Web Interface 1 2 3 4 5 6 7...
  • Page 19 Name Function Play Plays live video. Stop Stops playing video. Microphone Talks to the surveillance area from the local computer. Speaker Listens to the audio around the camera. Snapshot Takes a snapshot of live video. File Save Records live video to the local computer. Full Screen Switches to full screen view.

  • Page 20: Upgrading System Firmware

    Upgrading System Firmware GeoVision will periodically release the updated firmware on the website. To load the new firmware into the GV-Video Server, read the important notes below and then follow the instructions. Important: 1. While the firmware is being updated,...
  • Page 21 In this case, please contact your sales representative and send your device back to GeoVision for repair. For details on upgrading system firmware, see Advanced Applications, Chapter 6, GV-Video Server User's Manual on the software CD/DVD.

  • Page 22: Using The Web Interface

    Restoring to Default Settings You can restore the camera to factory default settings using the Web interface or directly on the GV-Video Server. Using the Web Interface: 1. On the left menu of Web interface, select Management and select Tools. The Additional Tools dialog appears. 2.
  • Page 23 Directly on the GV-Video Server: GV-VS04H / GV-VS14 1. Press and then release the Reset button immediately. 2. Press and hold the Load Default button until all 3 LEDs (Power, Ready and Disk Full/Fault) are on. This may take about 30 seconds.
  • Page 24 GV-VS11 GV-VS12 1. Unplug and plug the power cable to start. 2. Press and hold the Default button until the Ready LED blinks. This may take about 30 seconds. The Ready LED will blink twice. 3. Release the Default button. The process of loading default values is complete, and the GV-Video Server starts rebooting itself with the 2 LEDs turning off.
  • Page 25 GV-VS2420 / 2400 1. Press and then release the Reset button immediately. 2. Press and hold the Default button until the Ready LED blinks. This may take up to 30 seconds. The Ready LED will blink twice. 3. Release the Default button. The process of loading default values is complete, and the GV-Video Server starts rebooting itself with the Ready LED turning off.

  • Page 26: Connecting Auxiliary Devices

    Connecting Auxiliary Devices GV-VS04H / GV-VS14 and GV-VS2420 / 2400 GV-VS04H and GV-VS14 The 16-pin terminal block, located on the rear panel, provides interfaces for four digital inputs, four relay outputs, an RS-485 interface, a Wiegand interface, a GPS interface and auxiliary power. The terminal block can be...
  • Page 27 Pin Assignment The table below lists the pin assignment for the terminal block. GV-VS04H and GV-VS14 Function Function Relay Output 1 DC 5V Out for GV-Relay Module, or GPS Module Digital Input 1 Ground, or GPS Ground Relay Output 2...
  • Page 28 GV-VS11 The terminal block on the rear panel of GV-VS11 provides one digital input and output, an RS-485 interface and auxiliary power. - + 5V DI DO G Pin Assignment The table below lists the pin assignment for the terminal block. Function RS-485- RS-485-...
  • Page 29 GV-VS12 GV-VS12 provides the I/O Cable with RJ-45 Connector for the extensible connection to I/O devices and PTZ cameras. A RJ-45 connector and a bundle of shielded wires are on the each end of the cable. Pin Assignment The table below lists the pin assignment for the shielded wires of the I/O Cable with RJ-45 Connector.
  • Page 30 TX pin, and the GPS TX must be connected to the RX pin. For details, see Auxiliary Device Connectors, Chapter 9, GV-Video Server User's Manual on the software CD/DVD. 9F, No. 246, Sec. 1, Neihu Rd., Neihu District, Taipei, Taiwan Tel: +886-2-8797-8376 Fax: +886-2-8797-8335 support@geovision.com.tw http://www.geovision.com.tw...
