GeoVision VS04H Quick Start Manual page 12

8 Power LED
USB Port
9
10 Terminal Block
11 Gigabit Ethernet
Port
12 Power Out
13 Power In
Note: When transmitting video signals over a long distance, it is highly
recommended to use 5C-FB coaxial cables or above to minimize the
degradation of image quality. The transmission distance should be
within 300 m (984 ft).
This LED is on, indicating the power is
supplied.
2 USB ports for installing portable storage
devices.
The connectors for digital input, relay output,
and PTZ camera. See Chapter 9 Auxiliary
Device Connectors.
A plug for a 10/100/1000 Base-T Ethernet
A plug to power on the camera, by using the
optional DC Male-to-Male Cable, directly
through the GV-Video Server.
A plug for power input.
