No. Name
1 USB Port
2 Speaker Output
3 Audio Input
4 Video Input
5 Power In
6 Ethernet Port
7 USB Port
8 I/O / PTZ Port
9 RS-232
Terminal Block
10 Default Button
11 Ready LED
12 Power LED
Function
1 USB port for installing the portable storage
device.
A plug for the speaker device.
2 plugs for audio inputs.
2 plugs for video inputs.
A plug to power on the GV-Video Server.
A plug for inserting an Ethernet cable to build
the network connection.
1 USB port for installing the portable storage
device.
A port for digital input, relay output and PTZ
camera control. Insert the I/O Cable with RJ-45
Connector to this port.
The connectors for GPS module control.
It resets all configurations to their factory
settings. See 7 Restoring to Default Settings in
the Quick Start Guide.
This LED is on, indicating the GV-Video Server
is ready for connection.
This LED is on, indicating the power is
supplied.
