Installing on a Network

Here we use GV-VS04H as an example to demonstrate the basic
connections.
1. Connect your camera's video output to the BNC video input.
2. Connect the microphone to the RCA audio input using the 3.5 mm
Stereo to RCA Cable.
3. Connect the hub or switch on the LAN to the unit's 10/100 Mbps port.
4. Connect power using one of the following methods:
● Use the supplied power adapter, connect to power.
● Use the Power over Ethernet (PoE) function. The power is
provided over the network cable.
1
3
2
4
5
