12.
13.
14.

Resetting Firmware to the Factory Default Version

Occasionally the newly installed firmware may conflict with the system requirements. If that
occurs, it will be necessary to restore the original (factory-installed) default firmware using the
reset button, which is located in a recess on the base (see figure 14).
Use a screwdriver with a fine blade to press the reset button for 10 seconds while powering
on the DP DA2. The front panel power LED blinks amber three times, then lights solid amber,
and finally blinks amber three more times while the reset occurs. When the reset is complete, it
lights solid green.
Figure 14.
Figure 13. Firmware Loader Screen with a DP DA2 Added
If you want to remove a device from the Devices section, do the following:
a.
Click on the names of the devices to be deleted, to highlight them.
b. Select
Remove Selected Device(s)
c.
On the Remove Device(s) window, select or deselect any devices on the list as
desired, then click Remove
To remove all devices, select
Click Begin. The following indicators show the progress of the update:
The Transfer Time section shows the amounts of remaining and elapsed time for
•
the update.
The Total Progress section displays a progress bar with
•
In the Devices section, the Progress column displays an incrementing percentage
•
and another progress bar. The Status column displays
The upload is complete when the
column shows , and
100% Completed
field. Close the Firmware Loader window.
Status
Base of the DP DA2 showing the location of the firmware reset button
from the
Edit
.
Remove All Devices from the
Remaining Time field shows
is displayed above the progress bar and in the
DP DA2 • Updating Firmware
menu.
Edit menu.
above it.
Uploading...
.
Uploading
, the Progress
00.00.00
Reset Button
