Signal and HDCP LEDs
Signal LEDs
Input Signal LED — lights green when main link activity is
detected from source device connected to the input.
Output Signal LED — lights green when a main link signal is
being transmitted to at least one of the display devices connected to the outputs.
HDCP LEDs
Input HDCP LED — lights green when the source is HDCP encrypted and authenticated by the
DP DA2.
Output HDCP LED — lights green when the connected display device is HDCP compliant.
NOTE:
The HDCP LEDs will not light if the source device does not require HDCP
encryption or if the display devices are not HDCP compliant.
INPUT
OUTPUTS
SIGNAL
1
2
HDCP
DP DA2 • Panel Features
11
