Installing the Access Point
Figure 23: Mounting the AP150 Above a Suspended Ceiling
To mount an AP150 above suspended ceiling rails:
1.
2.
3.
Figure 24: Box Hanger Mounting Bracket Holes
4.
36 Meru Access Point Installation Guide
Height adjustment screw
Access Point 200
T-rail clips
Suspended ceiling T-rail
Determine the location on the ceiling rails where the AP will be mounted and remove the ceiling
tile.
Unpack the T-bar hanger kit and unfold the legs of the T-bar hanger.
Locate the bracket mounting clip holes on the mounting bracket (see
attaches the bracket perpendicular to the box hanger. The other mounts the bracket parallel to the
box hanger.
Mounting bracket holes
Attach the U-joint of the clip to the T-bar and snap in place (see
Bracket mounting clip
Mounting bracket
T-bar hanger
Antennas
Height adjustment screw
Figure 24). One hole
Figure 25).
