Figure 11 Mounting The Ap200 Above A Suspended Ceiling; Figure 12 Box Hanger Mounting Bracket Holes - Meru Networks ap150 Installation Manual

Height adjustment screw
Access Point 200
Suspended ceiling T-rail
Figure 11: Mounting the AP200 Above a Suspended Ceiling
To mount an AP200 above suspended ceiling rails:
1. Determine the location on the ceiling rails where the AP will be mounted and remove the ceiling
tile.
2. Unpack the T-bar hanger kit and unfold the legs of the T-bar hanger.
3.
Locate the bracket mounting clip holes on the mounting bracket (see
attaches the bracket perpendicular to the box hanger. The other mounts the bracket parallel to the
box hanger.
Figure 12: Box Hanger Mounting Bracket Holes
4. Attach the U-joint of the clip to the T-bar and snap in place (see
Bracket mounting clip
Antennas
T-rail clips
Mounting bracket holes
Installing the Access Point
Mounting bracket
T-bar hanger
Height adjustment screw
Figure
Figure 13).
12). One hole
Installing the AP200 17
