Summary of Contents for Meru Networks AP822

  • Page 1: Installation Guide

    Meru Networks AP822 Installation Guide xxx-xxxxx January 2014 Copyright © Meru Networks, Inc., 2003–2014. All rights reserved. Other names and brands may be claimed as the property of other...
  • Page 3 Limited Product Warranty This Limited Product Warranty applies to the original end-user customer of the Meru product which you purchased for your own use, and not for resale (“Product”), from Meru Networks, Inc. (“Meru”) or its authorized reseller (“Reseller”). Limited Warranties •...
  • Page 4 • Alteration or modification of the Product in any way, including without limitation configura- tion with software or components other than those supplied by Meru or integration with parts other than those supplied by Meru. • Abuse, damage or otherwise being subjected to problems caused by negligence or misap- plication (including without limitation improper or inadequate maintenance or calibration), relocation of the products (including without limitation damage caused by use of other than Meru shipping containers), or use of the products other than as specified in the applicable...
  • Page 5 at the address below. You agree to obtain adequate insurance to cover loss or damage to the Product during shipment. If you obtain an RMA# and return the defective Product as described above, Meru will pay the cost of returning the Product to Meru. Otherwise, you agree to bear such cost, and prior to receipt by Meru, you assume risk of any loss or damage to the Product.
  • Page 6 Meru. All inquiries or claims made under this Limited Product Warranty must be sent to Meru at the following address: Meru Networks Inc., 894 Ross Drive, CA 94087, USA Tel: 408-215-5300 Fax: 408-215-5301...

  • Page 7: Table Of Contents

    Table of Contents About AP822 ........11 Features .
  • Page 8 AP822 Mounting ....... . .21 Horizontally on a Shelf........21 Vertically on a Wall .
  • Page 9 FCC Guidelines ..........50 Industry Canada Guidelines .
  • Page 10 Table of Contents...

  • Page 11: About Ap822

    About AP822 The AP822 Access Point series delivers high performance, full-speed, Wi-Fi certified 802.11ac connectivity while simultaneously supporting legacy 802.11a/b/g/n devices. AP822 is available in two models AP822i and AP822e.

  • Page 12: Features

    MCS9/QAM-256 mode. IEEE Std 802.11ac in AP822 The AP822 series is the first of Meru access point family capable of operating in the IEEE Std 802.11ac mode, which is capable for theoretical throughput rates up to 866 Mbps per radio.

  • Page 13: Installation Location

    With grant of additional regulatory approvals and Permit-but-Ask by US Federal Communication Com- mission, users can configure two radios in AP822 on the same band (i.e., both radios are on the 2.4 GHz but in the different or same channels, or both radios are on the 5.x GHz but in the different or same channels).
  • Page 14 12Vdc, 2A. For Power over Ethernet, an 802.3af or 802.3at connection must be used. The AP822 is intended only for installation in Environment A as defined in IEEE Std 802.3af. All interconnected equipment must be contained within the same building, including the inter- connected equipment's associated LAN connection.

  • Page 15: Installing Ap822E

    Installing AP822e This chapter provides all the information that users need to install Meru AP822e. After user completing installation procedure, see the Meru System Director 6.1 Configuration guide for detailed instructions on the various configuration options. Follow all safety precautions mentioned in the “Safety Precautions”...

  • Page 16: Kensington Lock

    (G2) shall be disabled due to power limitations. AP822 is intended to be supplied by a UL listed power supply marked Class 2 or LPS and rated 12Vdc, 2A. If an optional power supply is used, it must be one supplied by Meru Networks.

  • Page 17: Ap822E Antennas

    AP822e Antennas Radio-Antenna-Port Mappings The following table lists which radio is associated with each antenna. TABLE 2: Radio-Antenna-Port Mappings Antenna Port Radio / Channel Radio 1 Radio 1 Radio 2 Radio 2 Attaching Antennas An AP822e has four external antenna ports, labeled A1, A3, A4 and A6, to be used for attach- ing the antennas supplied with the AP.
  • Page 18 AP822e Antennas...

  • Page 19: Installing Ap822I

    Installing AP822i This chapter provides all the information that users need to install Meru AP822i. After user completing installation procedure, see the Meru System Director 6.1 Configuration guide for detailed instructions on the various configuration options. Follow all safety precautions mentioned in the “Safety Precautions”...

  • Page 20: Kensington Lock

    (G2) shall be disabled due to power limitations. AP822i is intended to be supplied by a UL listed power supply marked Class 2 or LPS and rated 12Vdc, 2A. If an optional power supply is used, it must be one supplied by Meru Networks. Before You Begin...

  • Page 21: Ap822 Mounting

    Read and follow the regulatory instructions in Appendix A before installing and operating AP822. Horizontally on a Shelf When mounting an AP822 horizontally, place it on the desired surface and connect the power and network cables (G1 Ethernet Port is also used a PoE input). Optional stands (MNT-FEET-...

  • Page 22: Vertically On A Wall

    Vertically on a Wall Installation The AP822 ships with a metal bracket (650-00234) that can be used for wall mounting. This bracket is used in conjunction with the plastic 15/16” T-Bar Adapter/Wall Mount bracket (650- 00232) that easily locks the AP into place.
  • Page 23 User may mount the wall mount adapter directly to the wall mount bracket or use the included option spacers to allow additional clearance between the AP and bracket. See “AP822 Wall Bracket without spacers” on page 23 “AP822 Wall Bracket with spac- ers”...
  • Page 24 Use the 4 short screws for installation without spacers • Use the 4 long screws for installation with spacers Figure 6: AP822 adapter to the wall mount bracket Orient the AP so that the 2 mounting pins align with the receiving slots.
  • Page 25 Figure 7: Attaching the AP to the Wall Mount Figure 5 shows an AP822i model being attached to the bracket, but the process is identical for either The Meru logo on the front of the AP should face up and be readable. The ports on the AP should be in line with the cable cutout on the wall mount bracket.

  • Page 26: Box Mount

    To remove the AP from the wall mount, depress the locking mechanism tab toward the wall and slide the AP from right to left until it releases. Figure 9: AP822 removal Box Mount The accessory required for such installation is listed below:...

  • Page 27: Below A Standard Suspended Ceiling

    Follow the wall mount installation instructions as appropriate. Below a Standard Suspended Ceiling The provided ceiling mounting brackets allow the AP822 to attach to suspended ceiling T-rails. The AP ships with two different ceiling mounting bracket options to accommodate varying sizes of ceiling T-rails.
  • Page 28 AP Installation over Standard 9/16” or 15/16” T-Bar The accessory required for such installation is listed below: Item Model Number Quantity 15/16” T-bar & wall-mount combo adapter (650-00232) 9/16” T-bar adapter (650-00233) Orient T-Bar adapter/Wall mount adapter with the back of the AP, so that the 2 mounting pins align with the receiving slots.
  • Page 29 Position the AP up to the T-Bar at an angle and depress slightly to disengage T-Bar locks. Twist the AP clockwise to engage T-Bar locks. There should be 2 audible clicks. Verify that the AP comes online. AP Removal from Standard 9/16” or 15/16” T-Bar To remove the AP from ceiling, release the locking mechanism by pressing tab up, towards the ceiling and slide the AP from right to left until it releases.
  • Page 30 To remove the 15/16" T-Bar adapter/Wall mount adapter from the T-Bar, depress both T- Bar locks at the same time and twist counter-clockwise to release. AP Installation over Interlude & Silhouette T-Bars The accessory required for such installation is listed below: Item Model Number Quantity...
  • Page 31 Orient T-Bar adapter/Wall mount adapter with the back of the AP, so that the 2 mounting pins align with the receiving slots. Slide the adapter plate from left to right until the locking mechanism “clicks” into place.
  • Page 32 Install the optional accessory “MNT-SCRMKIT-04” to T-Bar. This is accomplished by loos- ening the two clamp screws, positioning the clamps over the T-Bar and re-tightening the screws until secure. Position the AP with the adapter plate installed, up to the T-Bar with the “MNT-SCRMKIT- 04”...

  • Page 33: Above A Standard Suspended Ceiling

    Verify that the AP comes online. AP Removal from Interlude & Silhouette T-Bar To remove the AP from ceiling, release the locking mechanism by pressing tab up, toward the ceiling and slide the AP from right to left until it releases. To remove the 15/16”...
  • Page 34 The AP822e with plastic cover removed is suitable for use in environmental air-handling space above a suspended ceiling in accordance with the Section 300-22(c) of the National Electric Code and Sections 2- 128.12 - 010 (3) and 12 - 100 of the Canadian Electrical Code. Part 1. C22. 1. Note that in order to comply with these standards, the plastic cover on the AP822e must be removed.

  • Page 35: Led Lights

    LED Lights When AP822 first connects to the controller (and any time the access point is rebooted), the AP initializes and then is programmed by the controller. When the AP first powers up, the LED is green. Thereafter, its color indicates its operating status.
  • Page 36 Figure 11: AP822 Status LED After the AP822 is connected, check the status of the LED. Its indicator state is described below. LED Lights...

  • Page 37: Led Activity And Meaning

    LED Activity and Meaning TABLE 4: LED Activity and Meaning COLOR STATE MEANING Status No Color — No power. Either there is no power or the LEDs are set to Off on the con- troller. Check the LED setting on the controller by clicking Configuration >...

  • Page 38: Next Steps

    Next Steps Now that the AP822 is installed, see the Meru System Director Getting Started Guide for instructions on initializing the hardware. Return to this chapter to check the status of the LEDs once the WLAN is operational. Next Steps...

  • Page 39: Approved Antennas

    Approved Antennas Only approved antennas may be used in conjunction with AP822 access points. Access Points have been designed to operate with the antennas listed below. Antennas not included in this list are strictly prohibited for use with these devices. The required antenna impedance is 50 ohms.

  • Page 41: Regulatory Information

    Inc. The correction of interference caused by such unauthorized modification, substitution or attachment is the responsibility of the user. Meru Networks, Inc. and its autho- rized resellers or distributors are not liable for any damage or violation of government regula-...

  • Page 42: Regulatory Specifications

    FCC Part 15.247 - 47 CFR Ch. I • FCC Part 15.407 - 47 CFR15.407 • RSS-210 • EN 300 328 • EN 301 893 • Japan Radio (Ninsho) Declaration of Conformity, Federal Communication Commission Manufacturer Information Meru Networks, Inc 894 Ross drive, Regulatory Specifications...

  • Page 43: Declaration Of Conformity

    Sunnyvale, CA 94089 Declaration of Conformity This device complies with Part 15 rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation.

  • Page 44: Declaration Of Conformity, Industry Canada

    Canada This equipment is in compliance with the essential requirements of other relevant provisions of Directive. Manufacturer Information Meru Networks, Inc 894 Ross drive, Sunnyvale, CA 94089 Declaration of Conformity The Class B digital portion of this apparatus complies with Canadian standard ICES-003.
  • Page 45 • These devices are not permitted to operate in the 5600 - 5650 MHz band (Ces appareils ne sont pas autorisés à opérer dans le 5600 - bande 5650 MHz.) For products available in the Canadian markets, only channels 1 through 11 can be operated. Selection of other channels is not authorized.

  • Page 46: Declaration Of Conformity, R&Tte Directive 1999/5/Ec

    To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Pour empecher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit etre utilze a l'interieur et devrait etre place lin des fenetres afin de Fournier un ecram de blindage maximal.
  • Page 47 EFTA Countries: Norway and Switzerland EU Applicants: Albania, Bosnia and Herzegovina EU Candidate: Iceland, Macedonia and Montenegro The following standards were applied: • EMC-EN 301.489-1 Article 3.1 (b) of R&TTE Directive; EN 301.489-17 Article 3.1 (b) of R&TTE Directive • Health &...
  • Page 48 • The conformity assessment procedure referred to in Article 10.4 and Annex III of Directive 1999/5/EC has been followed. Declaration of Conformity, R&TTE Directive 1999/5/EC...

  • Page 49: Vcci Statement

    This device is intended to be used in all EU and EFTA countries.   Device Name Certification Report Number AP822e CE 0980 AP822i CE 0980 VCCI Statement   English Translation This is a Class B product based on the standard of the Voluntary Control Council for Interfer- ence from Information Technology Equipment (VCCI).

  • Page 50: Fcc Guidelines

    As such the systems are designed to be operated as to avoid contact with the antennas by the end user. It is recommended to set the system in a location where the antennas can remain at least a minimum distance as specified from the user in accordance to the regulatory guide- lines which are designed to reduce the overall exposure of the user or operator.

  • Page 51: Industry Canada Guidelines

    The FCC recommends that if you are interested in further reducing your exposure then you can easily do so by reorienting antennas away from the user or placing the antennas at a greater separation distance then recommended or lowering the transmitter power output. Separation Distance Distance Limit...
  • Page 52 General Information of RF Exposure...

  • Page 53: Additional Notes

    With grant of additional regulatory approval and Permit-but-Ask, users may configure two radios in AP822 on the same band (i.e., both radios are on the 2.4 GHz but in the different or same channels, and both radios are on the 5.x GHz but in the different or same channels).

  • Page 54: Air Handling Space Requirements

    RF issues, including RF coverage, shall be the responsibility of the DAS vendor. Meru Networks recommends that customers use only a DAS that has been tested to work with Meru hardware and software. Meru does not provide any site surveys, design or implementa- tion of Wi-Fi over DAS.

  • Page 55: Restriction Of Hazardous Substances

    This device complies Administrative Measure on the Control of Pollution Caused by Electronic Information Products or China RoHS. AP822 may contain hazardous substances are marked with the EIP logo including an Environment Friendly Use Period (EFUP) value in 10 years.
  • Page 56 Restriction of Hazardous Substances...

  • Page 57: Cautions And Warnings

    Cautions and Warnings The cautions and warnings that appear in this manual are listed below in English, German, French, and Spanish. Changes or modifications not expressly approved by the party responsi- ble for compliance could void the user’s authority to operate the equipment. Cautions A Caution calls your attention to a possible hazard that can damage equipment.
  • Page 58 20 cm entre l'utilisateur (ou toute personne se trouvant à proximité) et les antennes du point d'accès. La potencia de radiación de los dispositivos de Meru Networks, Inc. está muy por debajo de los límites de exposición a radiofrecuencia estipulados por la. No obstante, los puntos de acceso de la serie Meru Access Point de Meru Networks, Inc.

  • Page 59: Warnings

    Exposure to Radio Frequency Radiation. The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit an RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s website http://www.hc-sc.gc.ca/rpb.
  • Page 60 With plastic covers removed, this product is suitable for use in environmental air-handling space in accordance with the Section 300-22(c) of the National Electric Code and Sections 2- 128.12 - 010 (3) and 12 - 100 of the Canadian Electrical Code. Part 1. C22. 1. For other countries, consult local authori- ties for regulations.
  • Page 61 Indoor antennas must be positioned to observe minimum separation of 20 cm. (~ 8 in.) from all users and bystanders. For the protection of personnel working in the vicinity of inside (downlink) antennas, the following guidelines for minimum distances between the human body and the antenna must be observed.
  • Page 62 Warnings...
