- Page 1 Ramboline dumb barge Order no. 3048/01...
- Page 2 We developed the Ramboline to be used in conjunction with the Ramborator. It is a dumb barge, or non-powered lighter, fitted with a radio-controlled bow flap which is actuated by a sailwinch. A bow thruster can be fitted for improved manoeuvrability.
- Page 3 150mm 2. Glue the carriageway deck girders 15a to the frames under the main deck 33. These parts are 495 mm long, and should be positioned with an adequate projection at front and rear. There should be a gap between the girders. Fig.
- Page 4 Fig. 7 7. Drill holes in the brass brackets 25 exactly as shown in the drawing alongside. Fit the two 80 mm lengths of brass rod 26 through the holes. 8. Fit the two brass brackets 25 in the openings in the deck from the underside.
- Page 5 12. Open up the bow thruster stubs (BSR). Slide the extension tubes 43 through the holes in the bow thruster box from the outside. Working inside the box, fit the extension tubes 43 on the bow thruster stubs. The glued joints between these parts must be watertight.
- Page 6 17. Assemble parts 35 and 36 to form the sailwinch fairing on the deck. Glue parts 37 and 38 together to form the fairing cover. When the sailwinch has been installed, secure the cover on the fairing using contact cement or similar. Glue parts 39 and 40 together, taking care to maintain the correct position of the screw-holes relative to the deck.
- Page 7 The support braces the servo when it is installed. Offer up the Ramborator to the Ramboline, and fit the coupling pin 69 (on the coupling shaft) between the brass brackets 25. Mark the position of the box on the deck of the Ramborator.
- Page 8 Fixogum or contact cement before fitting the retaining screws In its empty state the Ramboline draws about 1 cm, which means that the bow thruster is not then in the water; however, it is not required for steering the empty barge.
- Page 9 Matching springer tug RAMBORATOR Order No. 3048/00 Springer Tugs are self-propelled vessels employed on American rivers for transport duties and manoeuvring tasks; they are very simple and quick to construct. In model form they are also very simple, and since they can be built quickly, Springer Tug matches with these models rapidly developed in England and America.
- Page 10 Parts list Nr. Description Quant. Material Laser sheet Form Dimensions 1 Hull bottom Laser-cut 2 mm 2 Frame Laser-cut 2 mm 3 Frame Laser-cut 2 mm 4 Frame Laser-cut 2 mm 5 Frame Laser-cut 2 mm 6 Frame Laser-cut 2 mm 7 Frame Laser-cut 2 mm...
- Page 11 Nr. Description Quant. Material Laser sheet Form Dimensions 38 Sailwinch fairing, cap Laser-cut 1,5 mm 39 Electronics cover Laser-cut 2 mm 40 Inner electronics cover Laser-cut 2 mm 41 Inner bow thruster cover Laser-cut 2 mm 42 Bow thruster cap Laser-cut 2 mm 43 Bow thruster extension tube...
