Display Rotate Function - Cygnus M5-C2P Operating Manual

M5-CYG2P-M-01_Iss6.doc
5. When done press the Menu key
to save the new value.
Or press the Power / Cancel to
exit without saving.

Display Rotate Function

If the gauge is worn on a belt using the Krusell belt clip the end
display will be upside down. To rotate the display so it can be read
set the Display Rotate function to 'yes'. Now the thickness
measurement display will be rotated 180 degrees.
When you remove the gauge from the belt clip and access the
Main menu the display will rotate back the normal way around so
you can hold the gauge normally.
1. Press the Menu key
2. Press the Up Select key to get to
the Rotate Display item
3.
Press the Menu key to change
the value
4.
Use the Up and Down Select
keys to change the setting
between yes and no
Cygnus 2+ Operating Manual
47
