Measuring Higher Temperatures
The polyurethane membranes fitted to the single element probes
are suitable for measuring surface temperatures up to 70°C
(160°F). For measuring higher temperatures Teflon membranes
are available and suitable for surface temperatures up to 150°C
(300°F) with intermittent contact. Contact Cygnus instruments to
order Teflon membranes.
When measuring high temperatures limit the time the probe is in
contact with the hot surface to less than 4 seconds and ensure the
probe has sufficient time between measurements to cool down.

Summary of Cygnus Probes

Twin Element probes

Probe
Size
Type
T2C 12mm
T5B
8mm
T7A
5mm

Single Element probes

Probe
Size
Type
S2C
13mm
S2D
19mm
0.75"
Range in
Frequency Steel
(SE Mode)
2 MHz 2.5 to 250
mm
0.1 to 10"
5 MHz 1.5 to 200
mm
0.06 to 8"
7.5 MHz 0.8 to 50 mm
0.03 to 2"
Range in
Frequency
Steel
2.25 MHz 3 to 250 mm
2.25 MHz 3 to 250 mm
0.12 to 10"
Cygnus 2+ Operating Manual
Typical Uses
Attenuative materials
Cast irons, plastics
General purpose
Most metals
Thin metals
Typical Uses
General purpose probe suitable
for most applications that can
use Multiple Echo
measurement.
Coated metals
As S2C but has longer focal
point (33 mm) and narrower
beam so may perform better
on thicker materials
