Input / Output

EXBOX.BLDS detects the signal status of each MADI
input. A LED indicates the status (lock, sync, BLDS)
of each input discretely.
MADI 1 OUT
MADI 1 IN
MADI 2 OUT
MADI 2 IN
EXBOX.BLDS Manual - Version 1.3
SC socket
MADI 1 output - connect here for
MADI output signal.
SC socket
MADI 1 input - connect MADI
input signal here.
SC socket or BNC socket
MADI 2 output - connect here for
MADI output signal.
SC socket or BNC socket
MADI 2 input - connect MADI
input signal here.
