Input Switching
- automated (BLDS, Audio Pilote Tone)
- prioritized input
- carrier detection
- manual - push button or GPI
MADI 1
MADI 2
The BLDS signal for enhanced signal observation is
generated by a BLDS Generator and inserted into
the MADI stream by a DAW. The artifical design of
the control signal enables detection of signal loss or
corruption. An automated and inaudible switch-over is
executed within one sample.
Audio Pilote Tone means the presence of an audio
signal with a level > - 42 dBFS in channel 56 @ 1 FS
(28 @ 2 FS). Trigger after downtime > 10 ms.
EXBOX.BLDS Manual - Version 1.3
Parallel Output
- input signal status
- switching state
GPO
MADI 1
MADI 2
Chapter 1: Overview
Monitoring
