Priority Setting

Different characteristics of the MADI switch allow to
adapt varying scenarios. It ranges from manual input
selection to automated switching with prioritized
inputs with watchdog control or detection of either
BLDS or Audio Pilote Tone. Depending on the priority
setting the input can be selected manually.
The priority setting is adjusted by the blue push
button on the right side or alternatively by a GPI - see
„Control via GPI" on page 40.
Characteristic
manual switching
Priority condition: lock on
input #1 – revert to #1,
when lock is regained
Priority condition: lock on
input #2 – revert to #2,
when lock is regained
CHAPTER 4: Operation
EXBOX.BLDS Manual - Version 1.3
Input
Selection
yes
no
no
