page 54 of 64
CHAPTER 7: Technical Data
Dimensions
• Width 140 mm
• Height 42 mm
• Depth 146 mm
Weight
• 0.8 kg
Power Consumption
• 5 W (typical)
Power Supply
• 2 x Hirose socket (HR10)
• 9 V - 24 V DC (external)
WARNING
The connected power supply must provide a current
limiting to a maximum of 2.5 A.
Environmental Conditions
• Operating temperature +5°C up to +45°C
• Relative humidity: 10% - 80%, non condensing
CHAPTER 7: Technical Data
EXBOX.BLDS Manual - Version 1.3
