Pin
1
2
3
4
5
6
7
8
9
page 58 of 64
DSUB-9 (female) - GPO
5
9
Signal
N/C
N/C
GND
5P (+5 V)
5P (+5 V)
GND (FET)
GND (FET)
GND (FET)
GND (FET)
Appendix A - Wiring Sketches
4
3
2
1
8
7
6
Effect
GPO 1 (sync input 1)
GPO 2 (sync input 2)
GPO 3 (BLDS input 1)
GPO 4 (BLDS input 2)
EXBOX.BLDS Manual - Version 1.3
