Input State
Two LEDs each inform about the signal state of both
MADI inputs. For detection of the BLDS signal MADI
channels 8, 16, 24, 32, 40, 48, 56, 64 are observed.
LED (green) indicates the presence
of a BLDS signal at MADI input 1.
LED OFF
LED ON
LED heartbeat = watchdog active*
LED (green) indicates the presence
of a BLDS signal at MADI input 2.
LED OFF
LED ON
LED heartbeat = watchdog active*
* See „Watchdog" on page 41.
CHAPTER 4: Operation
= no BLDS signal detected
= BLDS signal detected
= no BLDS signal detected
= BLDS signal detected
EXBOX.BLDS Manual - Version 1.3
