LED Code
* See „Watchdog" on page 41
See „DSUB-9 (female) - GPO" on page 58 for
wiring details.
EXBOX.BLDS Manual - Version 1.3
GPO
Monitor
Input 1 is used for output –
BLDS present at output 1
3
or
watchdog active*
Input 2 is used for output –
BLDS present at output 2
4
or
watchdog active*
CHAPTER 4: Operation
page 45 of 64
