DSUB-9 (female) - GPI
5
9
Pin
Signal
1
N/C
2
N/C
3
GND
4
GND
5
GND
6
Voltage 1
7
Voltage 2
8
Voltage 3
9
Voltage 4
EXBOX.BLDS Manual - Version 1.3
4
3
2
1
8
7
6
Effect
GPI 1 (force input 1, watchdog)
GPI 2 (force input 2, watchdog)
GPI 3 (selection input)
GPI 4 (selection priority)
Appendix A - Wiring Sketches
page 57 of 64
