input / output
The EXBOX.BLDS detects the signal status of each
MADI input. A LED indicates the status (lock, sync,
BLDS) of each input discretely.
MADi 1 ouT
MADi 1 in
MADi 2 ouT
MADi 2 in
© 2014 DirectOut GmbH
®
sC socket (optical)
MADI output 1- connect here
for MADI output signal
sC socket (optical)
MADI input 1- connect the
MADI input signal here
sC socket (optical)
MADI output 2- connect here
for MADI output signal
sC socket (optical)
MADI input 2- connect the
MADI input signal here
EXBOX.BLDS Manual Version 1.1
Chapter 4: Operation
page 25 of 56
