SYNC 1
LED (green) indicates the lock /
sync state at MADI input 1.
LED OFF =
LED ON =
LED (green) indicates the lock /
SYNC 2
sync state at MADI input 2.
LED OFF =
LED ON =
NOTE
The synchronization of the BLDS signal takes a few
seconds. During this period the BLDS LEDs are
flashing.
EXBOX.BLDS Manual - Version 1.3
no signal or no lock or not in
sync with internal reference
signal is in sync with internal
reference
no signal or no lock or not in
sync with internal reference
signal is in sync with internal
reference
CHAPTER 4: Operation
page 31 of 64
