SYNC 1 LED (yellow) indicates the selection
of MADI input 1 for the output
signal.
LED OFF
LED blinking = MADI input 1 is selected
LED ON
LED (yellow) indicates the selection
SYNC 2
of MADI input 2 for the output
signal.
LED OFF
LED blinking = MADI input 2 is selected
LED ON
* See „Watchdog" on page 41.
The activation state of each port and the presence of
the BLDS signal is also monitored by four GPOs - see
„Monitoring via GPO" on page 44.
EXBOX.BLDS Manual - Version 1.3
= MADI input 1 is not
selected for the output.
for the output but no valid
signal is detected.
= MADI input 1 is selected
for the output.
= MADI input 2 is not
selected for the output.
for the output but no valid
signal is detected.
= MADI input 2 is selected
for the output.
