VLT HVAC Drive Design Guide
500-525 VAC, 50 Hz
I [A] Typical Motor Used [kW]
AHF,N
10
19
26
35
43
72
101
144
180
217
289
324
397
434
506
578
613
690 VAC, 50 Hz
I [A] Typical Motor Used [kW]
AHF,N
43
72
101
144
180
217
288
324
397
434
505
576
612
730
Table 4.3: * For higher currents, please contact Danfoss.
AHF 005
1.1 - 7.5 175G6644
11 175G6645
15 -18.5 175G6646
22 175G6647
30 175G6648
37 -45 175G6649
55 175G6650
75 - 90 175G6651
110 175G6652
132 175G6653
160 - 200 175G6654
250 175G6655
315 175G6652 + 175G6653
355 2x175G6653
400 175G6653 + 175G6654
450 2X 175G6654
500 175G6654 + 175G6655
AHF 005
45 130B2328
45 - 55 130B2330
75 - 90 130B2331
110 130B2333
132 130B2334
160 130B2335
200 - 250 2x130B2333
315 130B2334 + 130B2335
400 130B2334 + 130B2335
450 2x130B2335
500
560
630
710
