8 General Specifications and Troubleshooting
Mains Supply 3 x 525- 690 VAC
Max. input current
8
164
Typical Shaft output at 550
V [kW]
Typical Shaft output at 575
V [HP]
Typical Shaft output at 690
V [kW]
Enclosure IP21
Enclosure IP54
Enclosure IP00
Output current
Continuous
(at 550 V) [A]
Intermittent (60 sec over-
load)
(at 550 V) [A]
Continuous
(at 575/ 690 V) [A]
Intermittent (60 sec over-
load)
(at 575/ 690 V) [A]
Continuous KVA
(at 550 V) [KVA]
Continuous KVA
(at 575 V) [KVA]
Continuous KVA
(at 690 V) [KVA]
Continuous
(at 550 V ) [A]
Continuous
(at 575 V) [A]
Continuous
(at 690 V) [A]
Max. cable size, mains mo-
tor, load share and brake
2 x 70 (2 x 2/0)
[mm 2 (AWG)]
Max. external pre-fuses [A]
1
Estimated power loss
at rated max. load [W] 4) ,
600 V
Estimated power loss
at rated max. load [W] 4) ,
690 V
Weight,
Enclosure IP21, IP 54 [kg]
Weight,
Enclosure IP00 [kg]
Efficiency 4)
Output frequency
Heatsink overtemp. trip
Power card ambient trip
MG.11.B9.02 - VLT
P132 P160
110 132
150 200
132 160
D1 D1
D1 D1
D3 D3
162 201
178 221
155 192
171 211
154 191
154 191
185 229
158 198
151 189
155 197
2 x 70 (2 x 2/0)
315 350
2963 3430
3430 3612
96 104
82 91
0.98
0 - 600 Hz
85 °C 90 °C
60 °C
® is a registered Danfoss trademark
®
VLT HVAC Drive Design Guide
P200 P250
160 200
250 300
200 250
D2 D2
D2 D2
D4 D4
253 303
278 333
242 290
266 319
241 289
241 289
289 347
245 299
234 286
240 296
2 x 150 (2 x 300 2 x 150 (2 x 300
mcm) mcm)
350 400
4051 4867
4292 5156
125 136
112 123
110 °C 110 °C
