4 How to Order
4.2.6 Ordering Numbers: du/dt Filters, 380-480 VAC
Mains supply 3x380 to 3x480 VAC
Frequency converter size
380-439[VAC] 440-480 [VAC]
P11K
P15K
P18K
P22K
P30K
4 P37K
P45K
P55K
P75K
P90K
P110
P132
P160
P200
P250
P315
P355
P400
P450
P500
P560
P630
P710
P800
P1M0
NB!
See also Output Filter Design Guide, MG.90.Nx.yy
76
Minimum switching fre-
quency [kHz]
P11K 4
P15K 4
P18K 4
P22K 4
P30K 3
P37K 3
P45K 3
P55K 3
P75K 3
P90K 3
P110 3
P132 3
P160 3
P200 3
P250 3
P315 2
P355 2
P400 2
P450 2
P500 2
P560 2
P630 2
P710 2
P800 2
P1M0 2
2
MG.11.B9.02 - VLT
Maximum output frequen-
Part No. IP20 Part No. IP00
cy [Hz]
100 130B2396
100 130B2397
100 130B2397
100 130B2397
100 130B2398
100 130B2398
100 130B2399
100 130B2399
100 130B2400
100 130B2400
100 130B2401
100 130B2401
100 130B2402
100 130B2402
100 130B2277
100 130B2278
100 130B2278
100 130B2278
100 130B2278
100 130B2405
100 130B2405
100 130B2407
100 130B2407
100 130B2407
100 130B2407
100 130B2410
