Display Menu (Continue)

Auto Adjust

Image Position

Phase

Clock

Zoom In and Out

Document Number:

MAN – FD141CV-C-6

Automatically optimize your monitors image position, clock, and

phase.

Press the

and

area.

Press the

and

clear or sharpen the displayed characters.

Press the

and

visible on the screen background. The horizontal screen size will also

change.

Press the

and

display area. After you zoom in, the Horizontal and Vertical controls

are active. Use the

vertically within the zoomed area.

Rev:

buttons to change the image of the screen display

buttons to remove any horizontal distortion and

buttons to minimize any vertical bars or stripes

buttons to zoom in and out within the screen

and

buttons to move horizontally and
