This device is RDM ready. RDM stands for "remote device management" and makes remote control of devices
connected to the DMX-bus. ANSI E1.20-2006 by ESTA specifies the RDM standard as an extension of the
DMX512 protocol.
Manual settings like adjusting the DMX starting address are no longer needed. This is especially useful when
the device is installed in a remote area.
RDM ready and conventional DMX devices can be operated in one DMX line. The RDM protocol sends own
packages in the DMX512 data feed and does not influence conventional devices.
If DMX splitters are used and RDM control is to be used, these splitters must support RDM.
The number and type of RDM parameters depend on the RDM controller being used.
Display Settings
Shut off time
With this function you can shut off the color LCD display after 2 to 59 minutes. Turn the encoder in order to
select the desired shut off time. The default is 5 minute.
Filp Display
With this function you can the entire display to be flipped by 180˚ to allow for better view when the fixture is
hung from truss or a ceiling. This function is disabled as default.
Key Lock
With this function you can activate the automatic keylock status. If this function is activated, the keys will be
locked automatically after exiting the edit mode for 15 seconds. keeping press the [MENU] key for 3seconds if
you do not need this function.
Temperature C/F
With this function, Display the temperature for Celsius or Fahrenheit.
1．
Press ENTER, the display will show "Set".
2．
3．
4．
5．
Reset Default
With this function, you can select restore factory set for ON or OFF, the default is OFF.
1．
displayed. Press ENTER, the display will show "Personality".
2．
3．
4．
5．
Test
Home
With this function you can reset the device via the Control Board. You can select the different reset functions by turning
the encoder.
1． Tap <MODE/ESC>button, access the main menu Tap the <Up/Down>button until "Set" is
displayed. Press ENTER, the display will show "Set". Tap the <Up/Down>button until the display will
show "Disp.Setting". Press ENTER, the display will show "Disp.Setting".
2． Press <Up/Down> the display will show " Shutoff Time".
3． Press<ENTER> the display will show " Shutoff Time".
1． Tap <MODE/ESC>button, access the main menu Tap the <Up/Down>button until "Set" is
displayed. Press ENTER, the display will show "Set". Tap the <Up/Down>button until the display will
show "Disp.Setting". Press ENTER, the display will show "Disp.Setting".
2． Press <Up/Down> the display will show "Filp Display".
3． Press<ENTER> the display will show "Filp Display".
4． The display show "OFF", Press <Up/Down> the display will show "ON".
5． Press <ENTER>; to confirm or press <MODE/ESC>; to return to the main menu.
1． Tap <MODE/ESC>button, access the main menu Tap the <Up/Down>button until "Set" is
displayed. Press ENTER, the display will show "Set". Tap the <Up/Down>button until the display will
show "Disp.Setting". Press ENTER, the display will show "Disp.Setting".
2． Press <Up/Down> the display will show "Key Lock".
3． Press< ENTER> the display will show "Key Lock".
4． The display show "OFF", Press <Up/Down>;, the display will show "ON".
5． Press <ENTER>; to confirm or press &<MODE/ESC>; to return to the main menu.
Tap <MODE/ESC>button, access the main menu Tap the <Up/Down>button until " Set" is displayed.
Press <Up/Down>the display will show "Temp. C/F".
Press<ENTER> the display will show " Temp. C/F".
The display show "Celsius", Press <Up/Down> the display will show "Fahrenheit".
Press <ENTER>; to confirm or press <MODE/ESC>; to return to the main menu.
Tap <MODE/ESC>button, access the main menu Tap the <Up/Down>button until "Personality" is
Press <Up/Down>the display will show "Reset Default".
Press<ENTER> the display will show "Reset Default".
The display show "OFF", Press <Up/Down> the display will show "ON".
Press <ENTER>; to confirm or press <MODE/ESC>; to return to the main menu.
