Altronix R2432300UL Installation Manual page 2

These Altronix Rack Mount CCTV Power Supplies provide 24VAC or 28VAC distributed via thirty-two (32) fuse or PTC
protected outputs for powering CCTV Cameras, heaters and other video accessories.
Thirty-two (32) Output Rack Mount Configuration Reference Chart:
Altronix
Model Number
R2432300UL
R2432300ULCB
R2432600UL*
R2432600ULCB*
*24VAC models: Outputs 1-16 provide 12.5 amp (300VA) max. Outputs 17-32 provide 12.5 amp (300VA) max.
*28VAC models: Outputs 1-16 provide 10 amp (280VA) max. Outputs 17-32 provide 10 amp (280VA) max.
• UL Listed for Commercial CCTV Equipment (UL2044).
CUL Listed - CSA Standard C22.2 No.1-98, Audio,
Video and Similar Equipment.
• 2U rack mount chassis for use in standard EIA 19" rack.
• Removable terminal blocks with locking screw flange.
• Power switch with built-in circuit breaker.
• Thirty-two (32) individual power LED indicators.
1. The unit is factory set for 24VAC operation.
For 28VAC operation, adjust unit prior to mounting and applying power as follows:
a. Open bottom of unit by removing six (6) screws (Rack Mechanical Drawing & Dimensions, pg. 4).
b. Change the wire position so that the black wire [28V] is connected to the terminal marked [P] and
the yellow wire [24V] is connected to the terminal marked [S] (Fig. 1D, pg. 3).
c. After securing all wires for proper voltage place bottom panel back on the unit and fasten with the six (6) screws.
2. Mount unit in desired rack location (Space unit at least 3" from any video monitors), Do not obstruct side air vents.
3. Set power switch on back of unit to the OFF position (Fig. 1C, pg. 3).
4. Plug power cord into grounded 115VAC 50/60 Hz receptacle (Fig. 1B, pg. 3), ground should be connected
as indicated in (Fig. 1E, pg. 3).
5. Set power switch on back of unit to the ON (RESET) position and measure output voltage before
connecting devices (Fig. 1C, pg. 3). This helps avoid potential damage. All terminals with common
suffix (P) "1P, 2P..." are the same polarity.
6. Set power switch on back of unit to the OFF position (Fig. 1C, pg. 3).
7. Connect devices to removable terminal blocks marked [1P & 1N through 8P & 8N] (Fig. 1A, pg. 3).
When wiring is completed on terminal blocks they can be locked down by tightening screw flanges.
8. Upon completion of wiring, set power switch on back of unit to the ON (RESET) position (Fig. 1C, pg. 3).
9. Green power LEDs on faceplate will illuminate when AC power is present. When an output is in a trouble condition
(blown fuse or tripped PTC) the corresponding LED will not be illuminated (Fig. 1, pg. 3).
a. Blown fuse (R2432300UL & R2432600UL) - Set power switch on back of unit to the
OFF position (Fig. 1C, pg. 3). Remove front faceplate to access fuses.
24 12.5 amp (300VA)
28 10 amp (280VA)
24 12.5 amp (300VA)
28 10 amp (280VA)
24 25 amp (600VA)
28 20 amp (560VA)
24 25 amp (600VA)
28 20 amp (560VA)
Installation Instructions:
Overview:
32 - x
32 - x
32 x -
32 x -
32 - x
32 - x
32 x -
32 x -
Specifications:
• Surge suppression.
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates
costly labor.
Rack Dimensions:
3.25"H x 19.125"W x 8.5"D
- 2 -
3.5 amp 3 amp
3.5 amp 3 amp
2.5 amp 3 amp
2.5 amp 3 amp
3.5 amp 6 amp
3.5 amp 6 amp
2.5 amp 6 amp
2.5 amp 6 amp
