Features

The GO-5100M-PGE/GO-5100C-PGE is an industrial progressive scan camera equipped with a
2/3-inch global shutter CMOS image sensor with 5.1 effective megapixels (2464 × 2056). The unit is
compact and lightweight in design and is equipped with GigE Vision Ver. 1.1 interface.
™ The GO-5100M-PGE produces monochrome output while the GO-5100C-PGE produces Bayer output.
Compact and lightweight
The unit's compact size (approx. 29 × 29 × 41.5 mm, excluding lens mount) and lightweight design
(approx. 46 g) allows for easy assembly and installation.
Gigabit Ethernet interface supporting GigE Vision Ver. 1.1
• High-speed transfer at up to 1 Gbps of uncompressed data, the ideal format for image processing.
• Connection of multiple cameras and computers supported through use of a switching hub, etc.
• Maximum cable length of 100 m.
• Support for IEEE802.af-compliant PoE (Power over Ethernet) allowing you to supply power to the
camera via the LAN cable.
Note
Interface card or switching hub must support PoE. Alternatively, power can be supplied via the 6-pin connector
using an optional +12 to +24V DC power supply.
Output formats
You can choose from 8-bit, 10-bit, and 12-bit* output for both monochrome and Bayer.
* As the color camera cannot perform white balance when using 12-bit output, perform white balance on the
application.
High frame rate
The GO-5100M-PGE and GO-5100C-PGE are both capable of frame rates of up to 22.7 fps (8-bit
format) for full 5.1-megapixel output. Even faster frame rates can be achieved when binning is utilized
(GO-5100M-PGE only) or when a smaller ROI (region of interest) is specified.
ALC (automatic level control) function
Combine the automatic gain control and automatic exposure control functions to allow handling of
changes in various brightnesses.
Variety of pre-process functions
• LUT (lookup table)
For programmable control over gamma and contrast.
• Gamma correction
Gamma can be set to 0.45, 0.60, or 1.0 (off).
• Shading correction (flat field and color shading)
Non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment can
be corrected.
• Bayer white balance (GO-5100C-PGE only)
White balance can be automatically adjusted continuously. It can also be adjusted manually using R,
and B gain.
