JAI GO-5100C-PGE User Manual page 11

Recommended external output circuit diagram (reference example)
Standard circuit diagram example
User side
Userload
(resistor/lamp/relay/etc)
330~
OUT
2SC6033
USER POWER2
+5V to +24V
Characteristics of the recommended circuits for Opto OUT
OUTPUT LINE RESPONSE TIME
Camera
Output
Signal
Output
Line
Voltage
7 Camera locking screw holes (M3, 3 mm depth)
Use these holes when attaching an MP-43 tripod adapter plate (optional) or mounting the camera
directly to a wall or other structural system.
The smaller holes (×4) are M2 with a depth of 3 mm.
™
JAI
User
GO Series CAMERA
side
side
330
HIROSE_6Pin_NO.3 or 4
4k7
4k7
HIROSE_6Pin_No.5
2SC6033
RT
TDF
TDR
— 11 —
GO-5100M-PGE / GO-5100C-PGE
JAI camera
TLP109(TPR,E)
6
5
220BS
4
220BS
FT
90%
Output LEVEL = User Vcc- (0.8 to 1.1)
10%
OUT f rom camera
1
180BS
3
100KBS
