User Manual
PRELIMINARY

GOX-6409M-PGE / GOX-6409C-PGE
GOX-12409M-PGE / GOX-12409C-PGE
GOX-20409M-PGE / GOX-20409C-PGE
CMOS Digital Progressive Scan
Monochrome and Color Camera
Document Version: 0.1
GO-X_Series_RollingShutter_PGE_Ver.0.1_Sep2021
Thank you for purchasing this product.
           Be sure to read this manual before use.
This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read this manual to ensure proper operation.
The contents of this manual are subject to change without notice for the purpose of improvement.
@2021 JAI

Advertisement

Table of Contents
loading

Related Manuals for JAI GOX-6409M-PGE

Summary of Contents for JAI GOX-6409M-PGE

  • Page 1 User Manual PRELIMINARY    GOX-6409M-PGE / GOX-6409C-PGE GOX-12409M-PGE / GOX-12409C-PGE GOX-20409M-PGE / GOX-20409C-PGE CMOS Digital Progressive Scan Monochrome and Color Camera Document Version: 0.1 GO-X_Series_RollingShutter_PGE_Ver.0.1_Sep2021 Thank you for purchasing this product.             Be sure to read this manual before use. This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read this manual to ensure proper operation.  The contents of this manual are subject to change without notice for the purpose of improvement. @2021 JAI...

  • Page 2: Table Of Contents

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Table of Contents Notice/Warranty/Certifications ................5 Usage Precautions ......................8 Features .......................... 9 Parts Identification......................10 Preparation ......................14 Preparation Process ......................14 Step 1: Installing the Software (first time only) ..............14 Step 2: Connecting Devices .....................
  • Page 3 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) ROI Function (Single ROI) ....................45 Pulse Generator ......................46 CounterAndTimerControl Function ..................47 ChunkData Function......................49 Event Control Function ....................49 Action Control Function ....................50 PTP (Precision Time Protocol)................... 51 Setting List ......................52 Feature Properties ......................
  • Page 4 Index ........................78 About Technical Note Some additional technical information is provided on the JAI website as Technical Notes. In this manual, if a technical note is available for a particular topic, the above icon is shown. Please refer to the following URL for Technical notes.

  • Page 5: Notice/Warranty/Certifications

    The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
  • Page 6 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Supplement The following statement is related to the regulation on “Measures for the Administration of the control of Pollution by Electronic Information Products “, known as “China RoHS“. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years.
  • Page 7 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Supplement The following statement is related to the regulation on “Measures for the Administration of the control of Pollution by Electronic Information Products “, known as “China RoHS“. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years.

  • Page 8: Usage Precautions

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Usage Precautions Notes on cable configurations The presence of lighting equipment and television receivers nearby may result in video noise. In such cases, change the cable configurations or placement. Notes on LAN cable connection Secure the locking screws on the connector manually, Secure manually.

  • Page 9: Features

    Mono8, Mono10, Mono10Packed, Mono12, GOX-20409M-PGE Mono12Packed GOX-12409C-PGE Color models BayerRG8, BayerRG10, BayerRG10Packed, GOX-20409C-PGE BayerRG12, BayerRG12Packed • Backside illuminated sensor • Gamma correction circuit that uses lookup tables • Internal test signal for settings configuration • Compatible with free eBUS SDK for JAI...

  • Page 10: Parts Identification

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Connection example: PoE-compatible switching hub Camera AC adapter External Trigger Parts Identification ① Lens mount（C-mount） Mount a C-mount lens, microscope adapter, etc. here. ❖ Before mounting a lens, be sure to refer to “Step 2: Connecting Devices”...
  • Page 11 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) ③ POWER/TRIG LED Indicates the power and trigger input status. LED status and camera status Light Status Camera initializing. （Lit amber） Camera in operation. （Lit green） During operation in trigger mode, trigger signals are being input. （Blinking green）...
  • Page 12 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Recommended external input circuit diagram (reference example) Opto In + (Pin2) Opto In - (Pin3) Recommended external output circuit diagram (reference example) Opto Out + (Pin4) Opto Out - (Pin5) OPTO-In circuit characteristics...
  • Page 13 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Characteristics of the recommended circuits for Opto OUT OUTPUT LINE RESPONSE TIME For the operating conditions of applied voltage (User Power) +12V, load resistance 10kΩ, and cable length 1m, the timing is shown in the table below. Item Result (Typ) (μs)

  • Page 14: Preparation

    When using the camera for the first time, install the software for configuring and controlling the camera (eBUS SDK for JAI) on the computer. ❖ When you install eBUS SDK for JAI, eBUS SDK for JAI player will also be installed. Download the eBUS SDK for JAI from the JAI website.

  • Page 15: Step 2: Connecting Devices

    C-mount lenses with lens mount protrusions of 9 mm or less can be attached. • To prevent vignetting and to obtain the optimal resolution, use a lens that will cover the image sensor size. Model name Image Sensor GOX-6409M-PGE Mono 1 / 1.8 7.37 mm x 4.91 mm (8.86mm diagonal) inch GOX-6409C-PGE...
  • Page 16 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Caution • The maximum performance of the camera may not be realized depending on the lens. • Attaching a lens with a mount protrusion of 9 mm or longer may damage the lens or camera.

  • Page 17: Step 3: Verifying Camera Operation

    Step 4: Verifying the Connection between the Camera and PC Verify whether the camera is properly recognized via Control Tool. Connecting the Camera to Control Tool Startup eBUS Player for JAI eBUS Player for JAI eBUS Player for JAI startup screen appears.
  • Page 18 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Select the camera you want to configure. Click the Select / Connect button. The connected camera is listed. Please select one camera.
  • Page 19 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Check that the settings of the selected camera are displayed. Click the Device control button. The screen shown below will be displayed. In this window you can adjust various settings of the camera. This completes the procedure for verifying whether the camera is properly recognized and whether control and settings configuration are possible.

  • Page 20: Step 5: Changing The Camera Settings

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Step 5: Changing the Camera Settings This section explains how to change settings by describing the procedure for changing the output format as an example. Configuring the Output Format Configure the size, position, and pixel format of the images to be acquired. The factory settings are as follows.

  • Page 21: Step 6: Adjusting The Image Quality

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Step 6: Adjusting the Image Quality Display the camera image and adjust the image quality. Displaying the Image Display the image captured by the camera. When you click the Play button, the camera image appears in right area. Note: When a time-consuming process such as white balance is performed, this camera returns an Ack response when the process is completed.
  • Page 22 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Adjusting the Gain Adjust the image quality using the gain and white balance* functions. *) Color model only To adjust the image quality The Visibility must be changed from Beginner to Guru. Adjust the sensitivity via the analog gain (i.e., master gain).
  • Page 23 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Adjusting the White Balance* Adjust the white balance using the automatic adjustment function. Color model only. ■ Automatic white balance adjustment Place a white sheet of paper or similar object under the same lighting conditions as the intended subject, and zoom in to capture the white.

  • Page 24: Step 7: Saving The Settings

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Step 7: Saving the Settings The setting values configured in the player (eBUS SDK for JAI) will be deleted when the camera is turned off. By saving current setting values to user memory, you can load and recall them whenever necessary.

  • Page 25: Main Functions

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Main Functions Sensor Shutter Mode The rolling-shutter camera has two sensor shutter modes (Rolling and Global Reset). When using a rolling-shutter camera, the exposure and line readout are executed pixel row by pixel row, and the exposure timing can be specified by SensorShutterMode.
  • Page 26 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Global Reset Use Global Reset for applications with moving objects. When Global Reset is selected, moving objects can be captured without distortion as each pixel row begins exposing at the same time. However, in this mode, the exposure time becomes longer for the lower pixel rows, which results in a gradual increase in brightness from top to bottom.

  • Page 27: Acquisition Control

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Acquisition Control This camera has three Acquisition modes (SingleFrame, MultFrame, Continuous). Use the AcquisitionControl settings to perform operations and settings for image capture. SingleFrame When the AcquisitionStart command is executed, one frame of image is captured. MultiFrame When the AcquisitionStart command is executed, the number of frames set in AcquisitonFrameCount are acquired as images.

  • Page 28: Exposure Mode

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) The shortest frame period varies depending on the selected ROI, pixel format, and binning mode. The longest frame period varies depending on the SenorShutterMode or PixelFormat settings. Model Name Longest Frame Period GOX-6409MC-PGE SensorShutterMode: Rolling 0.56 Hz (Approx.
  • Page 29 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Actual Exposure Times The actual exposure time will consist of the image sensor’s offset duration (refer to the table below) added to the setting configured on the camera. Example for GOX-12409M-PGE The GOX-12409M-PGE camera is configured as follows: •...

  • Page 30: Trigger Control

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Trigger Control The camera allows the following controls to be performed via external trigger signals. TriggerSelector Description AcquisitionStart Start image acquisition in response to the external trigger signal input. AcquisitionEnd Stop image acquisition in response to the external trigger signal input. FrameStart Start exposure in response to the external signal input.

  • Page 31: Pixel Format

    ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ FrameStart ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ Related Setting Items: AcquisitionControl Pixel Format Selectable PixelFormat is as follows. GOX-6409M-PGE Monochrome model Mono8 GOX-6409C-PGE Color model BayerRG8 GOX-12409M-PGE...

  • Page 32: Gpio (Digital Input/Output Settings)

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) GPIO (Digital Input/Output Settings) The unit can input/output the following signals to and from external input/output connectors. External output Line2 : Opt Out DC IN / TRIG IN connector (6-pin round) External input Line5 : Opt In DC IN / TRIG IN connector (6-pin round) These signals can be used as triggers and other necessary signals within the camera or as signals...

  • Page 33: Videoprocessbypassmode

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) VideoProcessBypassMode The video process bypass mode is a function that bypasses internal video processing on the camera. When bypass is enabled, the sensor output and camera output data can be set to the same bit depth.
  • Page 34 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) 2. The Maximum Frame Rate (Image Sensor) FrameStartTrigger Off: Sensor_FR_TRIG_OFF[Hz] = 1000000 ÷ ( H_Period[us] x V_Period_TrigOff[H] ) FrameStartTrigger On: Sensor_FR_TRIG_ON[Hz] = 1000000 ÷ ( H_Period[us] x V_Period_TrigOn[H] ) Please refer to the tables below for H_Period, V_Period_TrigOff, and V_Period_TrigOn. Model PixelFormat H_Period[us]...
  • Page 35 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) 3. The Maximum Frame Rate (Shortest Trigger Cycle) A. During Continuous Operation (Frame Start trigger is ”Off”) FR_Cont[Hz] = MIN(Interface_FR, Sensor_FR_TRIG_OFF) B. When TriggerMode is ”On” (Frame Start trigger is ”On”) 1. First, calculate the maximum OverlapTime value for the shortest trigger cycle. [GOX-6409MC-PGE] MaxOverlapTime_TrOlrd[us] = (1000000/FR_Cont) - (V_Sync_TrigOn[H] - ExposureProhibitPeriod[H]) x H_Period[us]...

  • Page 36: Gain Control

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Gain Control Adjust the AnalogAll (master gain) setting first, and then adjust the AnalogRed, DigitalRed. Color Model Monochrome Model Automatic Gain Level Control Set GainAuto to Continuous to control the gain level automatically. When GainAuto is set to Continuous, you can configure the conditions for automatic adjustment in detail.

  • Page 37: White Balance

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) White Balance To adjust the white balance automatically, set BalanceWhiteAuto to Once (automatic adjustment only once) or Continuous (automatic adjustment always). The metering area can be limited for automatic adjustment. To limit the metering area, specify each of the 16 areas with AWBAreaSelector and set AWBAreaEnable to True or False.

  • Page 38: Alc (Automatic Level Control) Function

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) ALC (Automatic Level Control) Function The ALC (automatic level control) function combines the automatic gain control (AGC/Auto Gain Control) and automatic exposure control (ASC/Auto Shutter Control) functions, and is capable of handling various changes in brightness.The function operates as follows in response to changes in brightness.

  • Page 39: Gamma Function

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Gamma Function The Gamma function corrects the output signals from the camera beforehand (reverse correction), taking into consideration the light-emitting properties of the monitor display. As the light-emitting properties of the monitor are not linear, the entire image may be darker or the gradation in the dark areas may be less noticeable when camera outputs are displayed without processing.

  • Page 40: Lut (Lookup Table)

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) LUT (Lookup Table) The LUT function is used to generate a non-linear mapping between signal values captured on the sensor and those that are output from the camera. You can specify the output curve using 257 setting points (indexes). To Use the LUT Function Configure the settings as follows.

  • Page 41: Blemish Compensation

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Blemish Compensation Multiple defective pixels that are not adjacent to each other can occur on conventional CMOS sensor cameras. This camera features a function that interpolates defective pixels using the surrounding pixels. Up to 256 pixels can be corrected.
  • Page 42 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Manual Configuration Select the index in BlemishCompensationIndex. You can select from 1 to 256. However, configure the indexes in order starting with the smallest index. If you skip indexes while configuring settings, interpolation may not be performed.

  • Page 43: Shading Correction

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Shading Correction The ShadingCorrection function corrects non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment. Using this function allows correction even if top, bottom, left, and right shading is not symmetrical in relation to the center of the screen (H, V). Block size is 256 x 256 pixels.

  • Page 44: Binning Function

    The Binning function allows you to combine the signal values of clusters of adjacent pixels to create improved virtual pixels. Using the function results in images with lower pixel resolution and higher sensitivity. Model Name Horizontal Binning Vertical Binning GOX-6409M-PGE Digital addition or Digital addition or averaging processing averaging processing GOX-12409M-PGE...

  • Page 45: Roi Function (Single Roi)

    GOX-6409MC-PGE: 3088 GOX-6409MC-PGE: 2064 GOX-12409MC-PGE: 4016 GOX-12409MC-PGE: 3036 GOX-20409MC-PGE: 5472 GOX-20409MC-PGE: 3648 (*B) (*D) GOX-6409M-PGE: 1544 GOX-6409M-PGE: 1032 GOX-12409M-PGE: 2008 GOX-12409M-PGE: 1518 GOX-20409M-PGE: 2736 GOX-20409M-PGE: 1824 Offset X (pixels) Offset Y (lines) H Binning Off: 0 to （＊E） step 16...

  • Page 46: Pulse Generator

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Pulse Generator By using this function, any signal can be generated inside the camera. The following is an example of signal generation. Settings PulseGeneratorStartPoint = 2 PulseGeneratorEndPoint = 6 PulseGeneratorLength = 10 PulseGeneratorPulseWidth = 4 PulseGeneratorClearSyncMode = AsyncMode The table below shows the PulseGeneratorClearSource signals that can be set.

  • Page 47: Counterandtimercontrol Function

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) CounterAndTimerControl Function This camera supports only the counter function. The counter function counts up change points in the camera’s internal signals using the camera’s internal counter, and reads that information from the host side. This function is useful for verifying error conditions via the count value using internal camera operations.
  • Page 48 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Internal Camera Blocks To Use the Counter Function Configure the settings as follows. Four counters are available. Specify a counter (Counter0 to Counter3), and configure the settings. Item Setting value / Description selectable range Counter 0 ～...

  • Page 49: Chunkdata Function

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) ChunkData Function The ChunkData function adds camera configuration information to the image data that is output from the camera. Embedding camera configuration information in the image data allows you to use the serial number of the camera as a search key and find specific image data from among large volumes of image data.

  • Page 50: Action Control Function

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Action Control Function The Action Control function is a function that executes the pre-configured action when the camera receives action commands. Action commands can send both unicast and broadcast messages and give instructions for actions to multiple cameras simultaneously by broadcasting them. A camera that has this function can even give instructions for actions to different types of multiple cameras.

  • Page 51: Ptp (Precision Time Protocol)

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) PTP (Precision Time Protocol) The camera can work as the slave for Precision Time Protocol defined in IEEE 1588. When the IEEE 1588 master clock exists in the network where the camera is connected, this function synchronizes the camera to the time of the master clock.

  • Page 52: Setting List

    Setting List This camera complies with GenICam. Each setting item name conforms to GenICam SFNC (Standard Features Naming Convention). (There are some JAI-specific setting items). Each setting item is an integer type (IInteger), a real type (IFloat), an element enumeration type (IEnumeration), a character string (IString), a logical type (IBoolean), and a category type (ICategory) or a command type (ICommand) for executing the function.

  • Page 53: Feature Properties

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Feature Properties DeviceControl Display/configure information related to the device. Item Setting range Default value Description DeviceVendorName ー "JAI Corporation" Display the manufacturer name. DeviceModelName ー ー Display the model name. DeviceManufacturerInfo ー See the possibilities Display the manufacturer information.

  • Page 54: Imageformatcontrol

    ー BinningHorizontal 1: GOX-6409MC-PGE : 96～3088 step 16 GOX-12409MC-PGE : 96～4016 step 16 GOX-20409MC-PGE : 96～5472 step 16 BinningHorizontal 2: GOX-6409M-PGE : 48～1544 step 8 GOX-12409M-PGE : 48～2008 step 8 GOX-20409M-PGE : 48～2736 step 8 Set the image height. Height ー...
  • Page 55 Reverse pixels horizontally. (GOX-6409MC-PGE model only) ReverseY True, False False Reverse pixels vertically. (GOX-6409MC-PGE model only) monochrome model Set the pixel format. PixelFormat ー 0x01080001:Mono8 GOX-6409M-PGE color model 0x01080001:Mono8 0x01080009:BayerRG8 GOX-6409C-PGE 0x01080009:BayerRG8 GOX-12409M-PGE & GOX-20109M-PGE 0x01080001:Mono8 , 0x01100003:Mono10, 0x010C0004:Mono10Packed 0x01100005:Mono12, 0x010C0006:Mono12Packed GOX-12409C-PGE & GOX-20109C-PGE...

  • Page 56: Acquisitioncontrol

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) AcquisitionControl Configure image capture settings. Item Setting range Default value Description 0:SingleFrame 2:Continuous AcquisitionMode Select the image capture mode. 1:MultiFrame 2:Continuous AcquisitionStart ー ー Start image capture. AcquisitionStop ー ー Stop image capture. AcquisitionFrameCount 1～65535 In MultiFrame mode, set the number of frames to capture.

  • Page 57: Eventcontrol

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) EventControl Configure settings for event control. Item Setting range Default value Description Select the event to send the event message. AcquisitionTrigger EventSelector ー [setting range] 0:AcquisitionTrigger, 1:FrameStart, 2:FrameEnd, 5:ExposureStart, 6:ExposureEnd Sets whether or not to send an event message when an event selected by EventNotification Off, On [EventSelector] occurs.

  • Page 58: Analogcontrol

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) AnalogControl Configure analog control settings. Item Setting range Default value Description AnalogAll, Select the gain to configure. 0:AnalogAll GainSelector 1:DigitalRed, (DigitalRed and DigitalBlue are color model only) 2:DigitalBlue AnalogAll, x1.0 ー Set the gain value for the gain setting selected in [GainSelector]. Gain DigitalRed, x1.0 (DigitalRed and DigitalBlue are color model only)

  • Page 59: Digitaliocontrol

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) DigitalIOControl Configure settings for digital input/output. Item Setting range Default value Description 21:Line2 21:Line2 LineSelector Select the input/output to configure. 24:Line5 60:Nand0 In1 61:Nand0 In2 62:Nand1 In1 63:Nand1 In2 255:TimestampReset Select the line source signal for the item selected in [LineSelector]. LineSource ー...

  • Page 60: Pulsegenerator

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) PulseGenerator Configure pulse generator settings. Item Setting range Default value Description GOX-6409MC-PGE: 4 Set the division value for the prescaler (12 bit) using PixelClock as the base ClockPreScaler 1～4096 GOX-12409MC-PGE: 9 clock. GOX-20409MC-PGE: 9 GOX-6409MC-PGE: GOX-6409MC-PGE:...

  • Page 61: Lutcontrol

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) LUTControl Configure LUT settings. Item Setting range Default value Description LUTSelector Red, Green, Blue Select the LUT channel to control. (color model only) LUTIndex 0～256 Set the LUT index table number. LUTValue 0～4095 Gamma=1.0 Set the LUT value.

  • Page 62: Actioncontrol

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) GevGVCPExtendedStatusCodesSele Version1_1, ctor Version2_0 GevGVCPExtendedStatusCodes True, False GevGVCPPendingAck True, False GevGVCPExtendedIDMode Off, On 0:OpenAccess GevCCP ー Controls the device access privilege of an application. 1:ExclusiveAccess 2:ControlAccess 3:ControlAccessSwitchoverAc tive GevPrimaryApplicationSocket ー ー Returns the UDP source port of the primary application. GevPrimaryApplicationIPAddress ー...

  • Page 63: Usersetcontrol

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) UserSetControl Configure user settings. Item Setting range Default value Description Default, UserSet1, Default UserSetSelector Select the user settings. UserSet2, UserSet3 Read the user settings. UserSetLoad ー ー When Default is selected for UserSetSelector, the factory settings are read. UserSetSave ー...

  • Page 64: Autolevelcontrol

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) AutoLevelControl Configure Auto Level Control settings. Item Setting range Default value Description 0: Peak Channel, 1: Selected Channel ALCControlReference 1: Selected Channel 0:Red, 1: Green ALCControlChannel 1:Green, 2:Blue ALCReference 30～95 Set the target level for ALC. (unit: %) Select the area for which to configure [ALCAreaEnable].

  • Page 65: Blemishcontrol

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) BlemishControl Configure settings for JAI white blemish correction. Item Setting range Default value Description BlemishEnable True, False True Enable/disable blemish correction. Execute blemish detection. BlemishDetect ー ー This command cannot be executed under the following conditions.

  • Page 66: Counterandtimercontrol

    Display the count value. Display the counter status. CounterStatus ー ー 0:CounterIdle: Idle 2:CounterActive: Counting 4:CounterOverflow: Count value exceeded the maximum value ImagingControl Configure settings for other JAI functions. Item Setting range Default value Description VideoProcessBypassMode Off, On Enable/disable VideoProcessBypass mode.

  • Page 67: Miscellaneous

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Miscellaneous Troubleshooting Check the following before requesting help. If the problem persists, contact your local JAI distributor. Power Supply and Connections The POWER/TRIG LED remains lit amber and Camera initialization may not be complete does not turn green, even after power is due to lack of a power.

  • Page 68: Specifications

    GOX-20409Mc-PGE: 2.4μm x 2.4μm GOX-6409MC-PGE: 3088(H) x 2064(V) GOX-12409MC-PGE: 4016(H) x 3036(V) Effective image pixel GOX-20409MC-PGE: 5472(H) x 3648(V) Mono8 BayerRG8 GOX-6409M-PGE: 18.0 fps GOX-6409C-PGE: 18.0 fps 8bit GOX-12409M-PGE: 9.4 fps GOX-12409C-PGE: 9.4 fps GOX-20409M-PGE: 5.7 fps GOX-20409C-PGE: 5.7 fps...
  • Page 69 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) GOX-6409MC-PGE: 3088(H) x 2064(V) GOX-12409MC-PGE: 4016(H) x 3036(V) Full GOX-20409MC-PGE: 5472(H) x 3648(V) GOX-6409MC-PGE : 96 to 3088 step 16 GOX-12409MC-PGE : 96 to 4016 step 16 Width GOX-20409MC-PGE : 96 to 5472 step 16 GOX-6409MC-PGE : 0～2992 step 16 GOX-12409MC-PGE : 0～3920 step 16 Offset X...
  • Page 70 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Off(Default), 10μs, 100μs, 500μs, 1ms, 3ms, 5ms, 7ms, 10ms, 15ms, Opto filter 20ms, 25ms, 30ms, 35ms, 40ms Trigger overlap Off / Read out Low, High, Software, PulseGenerator0, Trigger input signals Action1, Action2, UserOutput0-3, Line5, NAND 0 Out, NAND 1 Out Exposure Timed...
  • Page 71 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Input range DC ＋ 10 V ～＋ 25 V （Via input terminal） 6-pin Connector 2.7 W（typ.）(at 12 V input, default setting, 25 ℃ environment） Consumption Power 3.4 W（max.） supply Input range DC ＋ 36 V ～＋ 57 V 3.7 W（typ.）(default setting, 25 ℃...

  • Page 72: Spectral Response (Gox-6409Mc

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Spectral Response (GOX-6409MC-PGE)

  • Page 73: Spectral Response (Gox-12409Mc

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Spectral Response (GOX-12409MC-PGE)

  • Page 74: Spectral Response (Gox-20409Mc

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Spectral Response (GOX-20409MC-PGE)

  • Page 75: Dimensions

    Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Dimensions...
  • Page 76 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Comparison of the Decibel Display and Multiplier Display Decibels [db] Multipliers [x] Remarks 0.501 0.562 0.631 0.708 0.794 0.891 1.122 1.259 1.413 1.585 1.778 1.995 2.239 2.512 2.818 3.162 3.548 3.981 4.467 5.012 5.623 6.31...
  • Page 77 Model name: …………… Revision: …………… Serial No: …………… Firmware version: …………… For camera revision history, please contact your local JAI distributor. Trademarks • Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries.
  • Page 78 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Index 6-pin round ........11 Lens mount ........10 Acquisition ........27 Lookup Table ........40 LUT ..........40 Adjusting the Black Level ....23 Parts Identification ......10 Adjusting the Gain ......22 ALC ..........
  • Page 79 Go-X Series Rolling Shutter GigE Vision I/F (Preliminary) Revision History Revision Date Changes Sep. 2021 Preliminary Version...
