HydraSwing
™
HydraSwing 40, 40F, 40 Twin, 40F Twin, 80F and 150
Programming & Operations Manual
with
HySecurity Smart Touch Controller
MX3636-01 Revision C
This document provides Important Safety Information, specifications, and references along with
an overview of programming user and installer menu options, designing vehicle loop layouts,
troubleshooting, and maintaining the gate operator.
