- Page 1 Operating and Installation Instructions Ceramic combiset with Induction CS 1212-1 en - CA To prevent accidents and machine damage, read the Operating Manual before installation or use. M.-Nr. 09 107 500...
-
Page 3: Table Of Contents
Contents Appliance description ..........4 Display . -
Page 4: Appliance Description
Appliance description a Cooking zone with Twin Booster Cooking zone control knobs: (BI/II) f rear b Cooking zone with Single Booster g front (BI) c Display d Symbols for the layout of the cooking zones Indicators Display e Indicators Display l Control panel m Booster display n Residual heat indicator... -
Page 5: Display
= Auto heat-up = Booster I = Booster II (only with appropriately equipped cooking zones) = System lock (see "Safety devices") Burner data Burner CS 1212-1 minimum to maximum C Rating in watts at 240 V** in cm* front 10 - 16... -
Page 6: Warning And Safety Instructions
All other types of use are not permitted. damage Miele cannot be held liable for damage resulting from incorrect or improper Keep these operating instructions in use. a safe place and pass them on to The cooktop is not intended for any future user. - Page 7 Warning and safety instructions Children Packing materials (e.g., foil, Styrofoam) can be dangerous for Activate the Child Safety Lock so children, Danger of suffocation. Ensure that children cannot turn the cooktop on that any packing material is disposed of inadvertently. safely and kept out of the reach of Always supervise any children in the children.
- Page 8 Installation, maintenance or repair work operate a damaged appliance. A by unqualified persons could pose damaged appliance is dangerous and serious risks to the user for which Miele poses a safety hazard. will not be held liable. The electrical safety of the cooktop...
- Page 9 Miele will not Do not leave the cooktop be held liable for damages resulting unattended while it is in use.
- Page 10 Warning and safety instructions Protect your hands when working NEVER use the appliance to heat up around the hot cooktop - wear closed containers, e.g., canned foods. heat-resistant oven mitts and use The increased pressure can cause the potholders, etc. Use only dry containers/cans to explode, and this potholders, make sure they are not carries the danger of injury and burns.
- Page 11 Miele cannot be held liable for underside of the appliance to ensure damage caused by failure to comply adequate ventilation. Sharp or small...
-
Page 12: Before Using For The First Time
Before using for the first time Heat the appliance Attach the data plate found in the documents for your appliance in the When the combiset is first connected to locations indicated in "Data Plate." the power supply and after a power failure, all indicators in the display will Clean the combiset light up for approx. -
Page 13: Induction
Induction How it works If no pan or an unsuitable pan is placed on the burner, the burner and the An induction coil is located under the combiset will switch off automatically burner. When the burner is switched after 3 minutes. 0 will flash alternately on, this coil creates a magnetic field with C in the display. -
Page 14: Noises
Induction Noises The appliance has a cooling fan to help extend the life of the electronics. When When using an induction burner, the the combiset is being used at high following noises can occur in the pan, levels for a long period of time, this will depending on what it is made of and come on and you will hear a whirring how it is constructed. -
Page 15: Cookware
Induction Cookware Make sure that you always place the pan in the middle of the burner. If Suitable pans include: the pan only partially covers the – stainless steel pans with a magnetic burner, the handle could become base very hot. –... -
Page 16: Use
Turning the combiset On/Off Residual heat indicator The residual heat indicator will go out Do not leave the appliance once the combiset has cooled to a safe unattended while in use. temperature. To turn the combiset on turn the control knob clockwise a to the desired power level. -
Page 17: Settings
Settings Use for Power level* Melting butter, chocolate, etc. 1 - 2 Dissolving gelatin Prepare yogurt Warming small quantities of food or liquid 1 - 3 Keeping delicate dishes warm Cooking rice, Thawing frozen vegetables Warming liquid or half-set foods 2 - 4 Thickening sauces, e.g., hollandaise sauce Cooking rice pudding... -
Page 18: Auto-Heat
Auto-heat Activating Auto-heat ^ Turn the control knob When Auto-heat has been activated, the burner switches on automatically at counterclockwise as far as it will go the highest setting and then switches to and hold until an A appears in the the continued power level which was display. -
Page 19: Booster Function
Booster function To activate Booster I ^ Turn the control knob past power The burner is equipped with a booster function to temporarily increase the level 9 to BI/II, then turn back to level power level. This boost is intended to quickly bring large quantities of water I appears in the display and the B to the boil, e.g. -
Page 20: Keep Warm
Keep warm Tips This function can be used for keeping – Cover the pan with a lid. food warm right after it has been – It is not necessary to stir the food cooked. It is not for reheating food while it is being kept warm. -
Page 21: Energy Saving Tips
Energy saving tips – Whenever possible, cook only in closed pots or pans. In this way, the heat is optimally dispersed. open closed – Use a small pot for small amounts. A small pot requires less energy than a larger pot that is only slightly filled. –... -
Page 22: Safety Features
Safety features Child Safety Lock Safety cut-out The combiset has a safety cut-out Keep children away from the feature in case it is not turned off after combiset for their own safety. use. The combiset has a Child Safety Lock If the burner is heated for an unusually to prevent children from turning on the long period of time (see table), and the... -
Page 23: Overheating Protection
– If an induction coil is affected, the If the overheating protection feature burner will turn off and an H will activates again, contact Miele appear in the display. Technical Service. ^ Turn the control knob to "0". -
Page 24: Cleaning And Care
Cleaning and care To avoid damage to the surface do Do not use a steam cleaner to not use any clean the appliance. Steam could – dishwashing liquid, penetrate electrical components and cause a short circuit. – cleaning agents containing soda, ammonia, alkaline, acid or chloride, –... - Page 25 Stubborn soiling is best removed (see "Optional accessories"). with a glass scraper. To help prevent rapid resoiling, we Next, clean the cooktop with the Miele recommend using a stainless steel ceramic and stainless steel cleaner conditioner (see "Optional (see "Optional accessories"), or a accessories").
-
Page 26: Troubleshooting
Troubleshooting You can easily resolve many of the minor problems you may encounter during everyday use. This saves time and money because you won't need to call Miele Customer Service. The following troubleshooting guide can help you. However, please note the following: Repairs should only be carried out by an authorized technician. - Page 27 Troubleshooting Problem Possible cause Solution The odour will diminish An odour or vapour appears when a new over time and eventually disappear. cooktop is switched The cooking zone No or unsuitable cookware Use suitable cookware display flashes the is present on the cooking (see "Cookware").
- Page 28 Troubleshooting Problem Possible cause Solution A cooking zone display The power level has alternatingly flashes C been reduced because and a power level. the booster was activated in the associated cooking zone. A cooking zone display Level II TwinBooster alternatingly flashes C was activated in the and 0.
- Page 29 Other fault messages There is a fault in the Interrupt the power supply to the FE.. electronics. cooktop for approx. 1 minute. If the problem persists after reconnecting the power supply, please contact Miele Customer Service.
-
Page 30: Technical Service, Data Plate
Technical Service, Data Plate In the event of a fault which you cannot easily fix yourself, please contact the Miele Technical Service Department at the address on the back of this booklet. When contacting Technical Service please quote the serial number and model of the appliance. -
Page 31: Installation Instructions
Installation Instructions IMPORTANT: SAVE FOR THE LOCAL ELECTRICAL INSPECTOR'S USE... -
Page 32: Safety Instructions For Installation
The cooktop must not be installed over a refrigerator or freezer, dishwasher, washer or dryer. Do not install this appliance above a Miele oven unless the countertop is at least 40 mm thick. - Page 33 Safety instructions for installation Upper clearance If there are several appliances beneath the exhaust hood, e.g., a wok burner and an electric cooktop, and there are different clearance distances listed in the Operating and installation instructions, always choose the greatest distance. For an exhaust hood above the appliance, always follow the safe clearance distance indicated by the...
- Page 34 2" (50mm) CS 1112 CS 1122 CS 1212 CS 1212-1 CS 1221 CS 1223 CS 1326 not recommended CS 1327 6" (150 mm)
- Page 35 Safety instructions for installation Minimum distance underneath Shelf To ensure proper ventilation of the Installation of an intermediate shelf appliance, a minimum distance below under the cooktop is not required but the appliance to an oven, intermediate allowed. shelf or drawer is required. For the positioning of the power cord a The minimum distance from the bottom gap of 10 mm is required at the rear.
-
Page 36: Installation
Installation Safety distance from the wall covering If a wall covering is installed, a minimum safety distance must be maintained between the countertop cut-out and the covering, since high temperatures can damage these materials. If the covering is made of a combustible material (such as wood), the distance between the countertop cut-out and the wall covering must be a minimum of 2"... -
Page 37: Appliance And Installation Dimensions
Appliance and installation dimensions a Spring clips b front c Installation height d Installation height of junction box with power cable, L = 2000 mm e Data plate... -
Page 38: Preparing The Worktop
Preparing the worktop ^ Make a countertop cut-out for one or more appliances according to the dimension diagram. Be sure to observe the minimum distance from the rear wall and to the left or right from a side wall. See the section on "Safety notices for installation". -
Page 39: Installation Of Multiple Appliances
Preparing the worktop Installation of multiple appliances When installing more than one combiset appliance, a support bar b must be installed between the appliances. Countertop cut-out Countertop cut-out two appliances three appliances For the installation of two appliances For the installation of three appliances the width of the countertop cut-out D is the width of the countertop cut-out D is the sum of A and C. - Page 40 Preparing the worktop Sample calculations for a countertop cut-out for three appliances appliance width appliance width appliance width Countertop minus " (8 mm) minus " (8 mm) cut-out 11" " 11" " (280 mm) (280 mm) (848 mm) (288 mm) 11"...
- Page 41 Preparing the worktop a Spring clips b Support bars c Space between support bar and countertop d Cover strip The illustration represents the attachment of spring clips a and support bars b for 3 appliances. An additional support bar is required for each additional appliance. The position for attachment of an additional support bar depends on the width of the appliance B (288 mm / 380 mm / 576 mm).
-
Page 42: Attaching The Spring Clips And Support Bars
Attaching the spring clips and support bars Wood countertop ^ Place the supplied spring clips a and the support bars b at the marked positions on the upper edge of the cut-out. ^ Use the supplied 3.5 x 25 mm screws to attach the spring clips and support bars. - Page 43 Attaching the spring clips and support bars Granite countertop Screws are not needed for stone countertops. ^ Coat the side and bottom edges of the spring clips a and support bars b with silicone. ^ Fill the space e between the support bars and the countertop with silicone.
-
Page 44: Installing The Appliance(S)
Installing the appliance(s) ^ Feed the appliance connection cable ^ Place the front edge of the next down through the worktop cut-out. appliance into the countertop cut-out. ^ Place the front edge of the appliance ^ Connect the appliance(s) to the into the countertop cut-out. -
Page 45: General Installation Tips
General installation tips Seal between appliance and Tiled surfaces countertop The sealing strip under the edge of the The grouting a and the shaded area top part of the appliance provides an below the appliance frame must be adequate seal with the countertop. smooth and flat, so that the frame will lie evenly and the sealing strip under The appliance must not be sealed... -
Page 46: Electrical Connection
Electrical connection Power supply CAUTION: Before installation or ^ Make sure your electrical supply servicing, disconnect the power matches the data plate. supply by either removing the fuse, shutting off the main power supply The combiset is equipped with a or manually "tripping"... -
Page 47: Help Protect Our Environment
Help protect our environment Disposal of packing materials Disposal of an old appliance The cardboard box and packing Old appliances contain materials that materials are biodegradable and can be recycled. Please contact your recyclable. Please recycle. local recycling authority about the possibility of recycling these materials. - Page 48 Alteration rights reserved / 2912 M.-Nr. 09 107 500 / 00 For the most updated manual, please visit the Miele web site.
