MANUAL
ENGLISH
WTF-FZ1500 1500W DMX Fazer
V1
Ordercode: 61133
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WTF-FZ1500 1500W DMX Fazer and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SHOWTEC WTF-FZ1500 1500W DMX Fazer

  • Page 1 MANUAL ENGLISH WTF-FZ1500 1500W DMX Fazer Ordercode: 61133 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    WTF-FZ1500 1500W DMX Fazer Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Overview ..................................6 Installation ................................... 7 Setup and Operation ................................ 7 Tank Hose Installation ..............................
  • Page 3: Warning

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● WTF-FZ1500 1500W DMX Fazer with a power cable (1,8 m) ● 1 x tank hose ●...
  • Page 4 ● If the WTF fails to work properly, discontinue use immediately. Remove all fog liquid from the tank. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service. ●...
  • Page 5: Operating Determinations

    Showtec is not liable for any consequential loss in the event of a WTF breakdown. This user manual has been drawn up with the utmost care. Showtec cannot be held responsible for any mistakes made in this publication or for any consequences thereof.
  • Page 6: Return Procedure

    WTF-FZ1500 1500W DMX Fazer Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER...
  • Page 7: Description Of The Device

    Description of the device Features The Showtec WTF series offers a range of fog and haze effect machines. The current range contains 2 foggers: the WTF-F800 and the WTF-F1000, that can fill your venue with fog in no time. The WTF-FZ1500 produces a more subtle, almost haze-like, smoke.
  • Page 8: Installation

    Carefully add a fog liquid to the fog liquid tank. Do not overfill the tank! Use the WTF only with the Showtec fog liquids (ordercodes: 60603, 60603B, 60629, 60637). Any other types of liquid can damage the unit.
  • Page 9: Tank Hose Installation

    WTF-FZ1500 1500W DMX Fazer Tank Hose Installation 01) Loosen the cap on the liquid input (09) and remove it. See Fig. 02. 02) Put the tank hose through the cap and attach it firmly to the liquid input (09). See Fig. 03.
  • Page 10: Control Modes

    WTF-FZ1500 1500W DMX Fazer Start-up Plug the power cord into a grounded electrical outlet. The machine will now re-heat to the proper operating temperature. Once the proper temperature has been reached, the main menu will appear. Control Modes There are 2 modes: ●...
  • Page 11: Fixture Linking

    WTF-FZ1500 1500W DMX Fazer Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support.
  • Page 12: Control Panel

    WTF-FZ1500 1500W DMX Fazer The WTF-FZ1500 can be operated with a controller in control mode or without the controller in stand- alone mode. Control Panel A) LCD display MENU button C) UP button D) DOWN button ENTER button Fig. 08 Control Mode The fixtures are individually addressed on a data-link and connected to the controller.
  • Page 13: Menu Overview

    WTF-FZ1500 1500W DMX Fazer Menu Overview Main Menu Options Plug the power cord into a grounded electrical outlet. The machine will now re-heat to the proper operating temperature. Once the proper temperature has been reached, the display will show the main menu.
  • Page 14: Interval Time

    WTF-FZ1500 1500W DMX Fazer 1. Interval Time In this menu you can set the interval, i.e. the time between fog bursts. 01) Press the MENU button until the display shows INTERVAL. 02) Press the UP/DOWN buttons to set the interval time. The adjustment range is 1–999 seconds.
  • Page 15: Quick Mode

    WTF-FZ1500 1500W DMX Fazer 8. Quick Mode In this menu you can set whether the device, upon power-up, will perform last action from before shutdown. 01) In main menu, press the MENU button until the display shows QUICK. 02) Press the UP/DOWN buttons to select ON/OFF.
  • Page 16: Channel (Sync)

    WTF-FZ1500 1500W DMX Fazer 1 Channel (Sync) Channel 1 – Faze effect 0–5 Faze effect OFF, fan speed: 20 % 6–255 Faze effect ON: 1–100 %, fan speed: 21–100 % 2 Channels Channel 1 – Faze effect 0–5 Faze effect OFF 6–255...
  • Page 17: Troubleshooting

    05) If all of the above appears to be O.K., plug the unit in again. 06) If you are unable to determine the cause of the problem, do not simply continue, as this may damage the device. 07) Return the WTF to your Showtec dealer. Ordercode: 61133...
  • Page 18: No Response To Dmx

    WTF-FZ1500 1500W DMX Fazer No Response to DMX Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction. 01) Check the DMX setting. Make sure that DMX addresses are correct. 02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
  • Page 19: Product Specifications

    WTF-FZ1500 1500W DMX Fazer Product Specifications Model: WTF-FZ1500 Input voltage: 220–240 V AC, 50/60 Hz Power consumption: 2640 W Heater: 1450 W Output: 6000 cu.ft/min Heating time: 1,5 minutes Tank capacity: Liquid consumption: 5,1 ml/min (full output) Control modes: Manual, DMX-512...
  • Page 20 ©2020 Showtec...
