- Page 1 MANUAL ENGLISH Single WDP-1 Pro Ordercode: 50758 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Single WDP-1 Pro Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Connection with the mains............................4 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Overview ..................................5 HTP (Highest Takes Precedence) ..........................6 Installation ................................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Single WDP-1 Pro ● Neutrik powerCON True1 power cable (1,2 m) ●... -
Page 4: Operating Determinations
● If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service. -
Page 5: Connection With The Mains
Single WDP-1 Pro Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK SILVER... -
Page 6: Description Of The Device
Features The Showtec Single WDP-1 Pro is a 1-channel DMX dimmer/switch with a built-in wireless DMX receiver. It is possible to mount the Single WDP-1 Pro to any wall, truss or a fixture which makes it suitable for any location. -
Page 7: Htp (Highest Takes Precedence)
Single WDP-1 Pro HTP (Highest Takes Precedence) If the DMX input value is higher than the fader (03/10) value, then the DMX input will take precedence over the fader input. Similarly, if the fader (03/10) value is higher than the DMX input value, then the fader input will take precedence over the DMX input. -
Page 8: Setup And Operation
Single WDP-1 Pro Setup and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 110 V specification product on 240 V power, or vice versa. Connect the device to the main power supply. -
Page 9: Control Panel
Single WDP-1 Pro Control Panel A) LED display DMX LED indicator C) MENU button D) UP button DOWN button Wireless DMX LED indicator Fig. 04 Control Mode The Single WDP-1 Pro is individually addressed on a data-link and connected to the controller. The fixtures respond to the DMX signal from the controller. -
Page 10: Main Menu Options
Single WDP-1 Pro Main Menu Options 1. Remote control/Manual control 2. DMX Addressing (Fun1) 3. Dimmer/Switch (Fun1) 4. Dimmer Limit (Fun1) 5. WDP Control (Fun1) 6. Dimmer Preset (Fun2) 7. Full On (Fun2) 1. Remote Control/Manual Control 01) Press the MENU button until the display shows 02) Press the UP/DOWN buttons to choose between (DMX/wireless DMX receiver enabled) and (manual mode). -
Page 11: Full On (Fun2)
04) If you are unable to determine the cause of the problem, do not open the Single WDP-1 Pro, as this may damage the unit and the warranty will become void. 05) Return the device to your Showtec dealer. Ordercode: 50758... -
Page 12: Product Specifications
Single WDP-1 Pro Product Specifications Model: Showtec Single WDP-1 Pro Input voltage: 230 V AC, 50 Hz Fuse: F10L/250V Dimensions: 134 x 99 x 293 mm (LxWxH) Weight: 1,4 kg Operation Signal input: 5-pin DMX IN Signal output: 5-pin DMX OUT... -
Page 13: Notes
Single WDP-1 Pro Notes Ordercode: 50758... - Page 14 Single WDP-1 Pro Ordercode: 50758...
- Page 15 Single WDP-1 Pro Ordercode: 50758...
- Page 16 ©2020 Showtec...
