- Page 1 Z200 PI20 Power Everpac Instructi ons for installati on and use English More documents on: www.zodiac-poolcare.com H0548500.A - 2015/11...
-
Page 2: Table Of Contents
It is prohibited to distribute or modify this document in any way without authorisati on from • Zodiac®. Zodiac® is constantly developing its products to improve their quality; therefore, the • informati on contained in this document may be modifi ed without noti ce. -
Page 3: ❶ Specifi Cati Ons
❶ Specifi cati ons 1.1 I Descripti on *In the polystyrene cap above the heat pump Z200 PI20 Power Everpac with plug with plug Supply cable except PI2051 except 11M Joint (x2) Screw-in connector (x2) Ø40 adaptati on (x2) Ø50 reducti on (x2) Condensati on evacuati on kit (Ø15) Wintering cap (x2) Wintering cover... -
Page 4: I Technical Specifi Cati Ons
1.2 I Technical specifi cati ons Z200 PI20 PI2021 PI2031 PI2041 PI2051 Power Everpac 7 to 32°C Operati ng temperature range water up to 32°C Voltage 230V-50Hz Acceptable variati on in voltage -10%, +7% (during operati on) Nominal absorbed intensity 4.45 7.09 9.09... -
Page 5: ❷ Installati On
❷ Installati on 2.1 I Selecti ng the locati on • Do not lift the device by the body; use its base. • The device must be installed at a minimum distance from the pool's surrounding edge. This distance is determined by the electrical standards which apply in the installati on country. •... -
Page 6: I Hydraulic Connecti Ons
2.2 I Hydraulic connecti ons • The device will be connected with a Ø40 or Ø50 PVC pipe, using the connectors supplied (see § “1.1 I Descripti on”), to the pool's fi ltrati on circuit, aft er the fi lter and before the water treatment. •... -
Page 7: I Electricity Supply Connecti Ons
2.3 I Electricity supply connecti ons Incorrectly ti ghtened terminals may cause the terminal unit to heat up and invalidate the • warranty. • Before any work inside the device, you must cut the electricity supply as there is a risk of electric shock which may cause material damage, serious injury or even death. -
Page 8: I Opti On Connecti On
2.4 I Opti on connecti on 2.4.1 "Heati ng priority" opti on (depending on model) • This functi on helps to keep the water temperature constant by checking the water temperature at regular ti me intervals (minimum 5 minute cycle every 220 minutes (modifi able ti me)) by fi ltrati on pump control. The fi ltrati on is kept operati ng while the pool temperature is below the temperature requested. -
Page 9: ❸ Use
❸ Use 3.1 I Operati ng principle Your heat pump uses the calories (heat) in the air to heat up your pool's water. The process to heat your pool's water to the temperature you want may take a few days as it depends on the weather conditi ons, your heat pump's power and the diff... -
Page 10: I Operati Ng
3.3 I Operati ng • Check that there are no tools or other foreign objects in the machine. • The panel that provides access to the technical secti on must be put in place. • Set the valves as follows: valve B wide open, valves A, C, D and E closed : water entry valve : by-pass valve : water exit valve... -
Page 11: I User Functi Ons
3.4 I User functi ons 3.4.1 Water temperature reading When the water is circulati ng through the heat pump, press fl ashes for 10 seconds then the setpoint temperature is displayed fi xed. 3.4.2 Locking/unlocking the keyboard Locking the keyboard Unlocking the keyboard Press and hold for 3 seconds... -
Page 12: ❹ Maintenance
❹ Maintenance 4.1 I Wintering • Wintering is vital to prevent the condenser breaking due to freezing. This is not covered by the warranty. • To avoid damaging the equipment with condensati on, do not fully cover it. • Switch off the device by pressing and holding for 2 seconds and disconnect it or switch off... -
Page 13: ❺ Troubleshooti Ng
❺ Troubleshooti ng • Before you contact your reseller, please carry out these few simple checks using the following tables if a problem occurs. • If the problem conti nues contact your reseller. • : Acti ons reserved for a qualifi ed technician 5.1 I Device behaviour •... -
Page 14: I Error Code Display
5.2 I Error code display Display of Possible causes Soluti ons SD2 sensor is offl ine or incorrectly Sensor replacement connected Air temperature sensor fault SD3 sensor is offl ine or incorrectly Sensor replacement connected Deicing sensor fault Low pressure fault in the cooling circuit (if fault persists aft er Call an approved technician acknowledgement) -
Page 15: I Wiring Diagrams
5.3 I Wiring diagrams L-N-PE 230V-1N-50Hz protected power supply Venti lator relay Digital display Auxiliary pump relay Earth Complementary relay Compressor condenser Compressor Venti lator condenser Venti lator Flow controller Water temperature sensor High pressure switch Air temperature sensor Low pressure switch Defrost sensor Fuse Transformer... - Page 16 Votre revendeur Your retailer Modèle appareil Appliance model Numéro de série Serial number Trouvez plus d’informations et enregistrez votre produit sur More informations and register you product on www.zodiac-poolcare.com ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license.
