Specifications

3. Specifications
This chapter provides the various specifications in regard to all three HLX-40
control panels.
3.1

RF Data

RF Unit Type
Antenna Type
Operating
Frequencies
Receiver
Sensitivity
Transmitter
Power
Range
(open field)
RF Device ID
Coding
The HLX-40 system has optimum range if installed according to the
manufacturer's recommendations, though this range may be affected by radio
noise from high-power nearby sources, or interference with the signal
(blocking) by large metal surfaces, or multiple concrete walls.
3.2

Environmental Data

Operation
Temperature
Range
Storage
Temperature
Range
Relative
Humidity
Dimensions
(L x W x D)
Weight
16
Integrated RF transceiver (two-way) shielded super heterodyne,
fixed frequency
Printed PCB type antenna
G series – 433.92 MHz
H series – 868.35 MHz
Up to -68 dBm (without GSM Stick)
Up to +10 dBm, less based on country requirements
Up to 250 m in open space for detectors, and 110 m for hand-
held remote controls (without GSM Stick)
Three-bytes non-replicated per sensor type, or multiples of 16
million possible codes, make it almost impossible to have two like
coded transmitters
HLX-40
-25ºC to 70ºC (-13ºF to 158ºF)
85% at 30ºC (non-condensing)
217 x 144 x 48 mm
(8.5 x 5.7 x 1.9 in.)
520 g
(1.1 lb)
HLX-40 Hardware Installation and Programming Manual
HLX-40A
0ºC to 60ºC (32ºF to 140ºF)
217 x 144 x 50 mm
(8.5 x 5.7 x 2.0 in.)
548 g
(1.2 lb)
HLX-40B
217 x 144 x 48 mm
(8.5 x 5.7 x 1.9 in.)
530 g
(1.2 lb)
