Connecting To A Pc; Mounting The Back Plate; General; Figure 14: Back Plate Wiring - Rosslare HLX-40 Installation And Programming Manual

Advanced wireless security panel

Hide thumbs Also See for HLX-40:

Table of Contents

Installation

4.7

Connecting to a PC

The control panel can be equipped with an optional MD-62 adaptor for serial

data interchange with a computer.

4.8

4.8.1

To complete the installation without exposed wires, all the wiring should be

done through the wall. The wiring to the back plate can be done without

having exposed wires, by installing the panel on a standard electrical box, or

making a hole in the wall for the wiring (Figure 14).

It is important to mount the back plate first before connecting any of the wiring

to the unit.

When drilling the hole for the wires, it is recommended to drill the hole in the

marked out area (Figure 15).
