NOTE
Look for the AVTECH logo. Using another power adapter could
damage the Room Alert 4E's circuit board. If you need one, purchase
it online at
adapter with a compatible plug style for each and every country.
Ethernet Port
Digital Sensor Ports
Switch Sensor Channel

Back

Reset Button
AVTECH Software, Inc.
.com. AVTECH has an international power
An RJ-45 port connects Room Alert 4E to your network
via an RJ-45 network cable.
Two (2) standard RJ-11 jacks connect any AVTECH
digital sensor to your Room Alert 4E via a standard RJ-
11 (straight through) telephone cord.
A pair of dry contacts connects Room Alert 4E to any
AVTECH switch sensor via standard speaker wire or
low-voltage 2-wire cable.
A small push button resets Room Alert 4E to factory
default settings.
Room Alert 4E
5
