1. Verify that the terminal, laptop, or terminal server that will connect to the
chassis is operational.
2. Configure the terminal device or terminal emulation software with these
settings:
■
■
■
3. Connect a serial cable from the chassis serial port to the terminal device.
Refer to the modular system chassis documentation for the location of the serial
port.
The serial port requires a cable with these pin assignments.
Pin
1
2
3
4
5
6
7
8
4. Press Enter on the terminal device.
The connection between the terminal device and the CMM is established.
If you connected to the serial port before the powering on the modular system,
you will see boot messages. The CMM ILOM software displays its login prompt:
ORACLECMMnnnnnnnnnn login:
The first string in the prompt is the default host name, which consists of the prefix
ORACLECMM followed by the CMM ILOM MAC address. The MAC address for
each CMM and SP is unique.
32 SPARC T4-1B Server Module Installation Guide • May 2012
8N1 (eight data bits, no parity, one stop bit)
9600 baud (the default, but can be set to any standard rate up to 57600)
Disable hardware flow control (CTS/RTS)
Signal Description
Request To Send (RTS)
Data Terminal Ready (DTR)
Transmit Data (TXD)
Ground
Ground
Receive Data (RXD)
Data Carrier Detect (DCD)
Clear To Send (CTS)
