Method Connection Description
1 Ethernet
From: CMM NET MGT port
To: Your network
2 Serial
From: CMM SER MGT port
To: Terminal device
3 Serial
From: Server module SP
UCP port (dongle required)
To: Terminal device
16 SPARC T4-1B Server Module Installation Guide • May 2012
Connection Requirements
The CMM NET MGT port must be connected to your
network.
You must know the IP addresses of the CMM.
From your network, you must be able to log in to
Oracle ILOM on the CMM using the IP address of the
CMM. Then you can use the Oracle ILOM proxy to
navigate to the server module SP Oracle ILOM
interface.
See "Method 1a – Power On the Host Through the
CMM (Web Interface)" on page 28
Power On the Host Through the CMM (CLI)" on
page 29.
A terminal device connected to the CMM SER MGT
RJ-45 port. From this connection, you can use Oracle
ILOM to navigate to the server module SP Oracle
ILOM CLI interface. See
Host Through the CMM SER MGT Port (CLI)" on
page 31.
A UCP-3 dongle cable that connects directly to the
server module and a terminal device connected to the
RJ-45 connector on the dongle cable. See
Power On the Host Through the Front Panel (SP CLI)"
on page 34.
and "Method 1b –
"Method 2 – Power On the
"Method 3 –
Supported
Interfaces
a) CMM Oracle
ILOM web
interface
b) CLI
CMM Oracle
ILOM CLI
SP Oracle
ILOM CLI
