R
SPRT
SP－POS58III
Line Thermal Printer
User's Manual
Beijing Spirit Technology
Development Co, Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-POS58III and is the answer not in the manual?

Questions and answers

Related Manuals for SPRT SP-POS58III

Summary of Contents for SPRT SP-POS58III

  • Page 1 SPRT SP－POS58III Line Thermal Printer User’s Manual Beijing Spirit Technology Development Co, Ltd.

  • Page 2: Table Of Contents

    SPRT Content Chapter 1 Feature and Performance ..................２ 1.1 Print Performance .....................２ 1.2 Print Paper .........................２ 1.3 Print Font ........................２ 1.4 Interface........................２ 1.5 Print Control Command ...................３ 1.6 Power Supply ......................３ 1.7 Operation Environment ....................３ 1.8 Outline Dimension .....................３ Chapter 2 Installation and Operation ..................３...

  • Page 3: Chapter 1 Feature And Performance

    SPRT Chapter 1 Feature and Performance 1.1 Print Performance ● Print method: direct thermal ● Print paper width: 57.5±0.5mm ● Print density: 8 dots/mm, 384 dots/line ● Print speed: approx. 60mm／sec. ● Reliability: Print head life: 100km Using condition: ＊ Print 12 × 24 ASCII characters, print 50 lines each time, intermittent print repeatedly ＊...

  • Page 4: Print Control Command

    SPRT ● Parallel interface: DB25 socket (male), 8-bit parallel interface, supports BUSY/ACK handshaking protocol, TTL signal level. ● Ethernet interface: It can work under the Full-duplex or half-duplex mode and support Ethernet 802.3 protocol, the TCP、 UDP、 ICMP、 IP、 ARP、 HTTP printing agreement.
  • Page 5 SPRT Platen Upper Cover Housing Paper Sensor Paper Roll Print Head Sensor Indicator FEED Button Power Indicator Fig.2-1 Printer Appearance Power Switch Communication Interface Power Port Cash Drawer Port Case Base Fig.2-2 Printer Appearance ４...

  • Page 6: Paper Installation

    Please should not use hand to draw the paper ahead or backwards. 2.3 Interface Connection 2.3.1 Serial Interface Connection The serial interface of SP-POS58III printer is compatible with RS232C standard, supports RTS/CTS handshaking protocol, it uses DB25 socket (female), the pin order of the serial port is as Fig.2-4 shows: Fig.2-4 Pin Order of the Serial Interface...

  • Page 7: Parallel Interface Connection

    The baud rate and data structure in serial interface mode are set to 9600bps, 8 data bits, no parity bit and 1 stop bit. The serial interface of SP-POS58III can be connected to standard RS-232C interface. When connected to IBM PC or compatible machine, connection can accord to Fig.2-6.
  • Page 8 SPRT Fig.2-7 Pin Order of Parallel Port The pin assignment of parallel interface is shown in Fig. 2-8 shows: Pin No. Signal Direction Description Strobe pulse to latch data, /STB reading occurs at falling edge. DATA1 These signals represent the 1...

  • Page 9: Ethernet Interface

    TCP/IP, ICMP, ARP agreements. It can be used to print internet data. As following fig.2-9 shows: Fig.2-9 Ethernet Interface 2.3.3 Cash Drawer Interface The cash drawer interface of SP-POS58III adopts RJ-11 6-pin socket, as Fig.2-10 shows: Fig. 2-10 Cash Drawer Interface The pin assignment of the cash drawer interface is as follows: Pin No.

  • Page 10: Power Connection

    SPRT 2.3.4 Power Connection SP-POS58III uses external power supply as 12V, 2A, power socket is A-1009-3P model, as Fig. 2-9 shows: Fig.2-9 Power Socket 2.4 Buttons and Indicators Power Switch: control the power on or off status. is power off status, “－”...

  • Page 11: Command Specifications

    SPRT SP-POS58III offers ESC/POS print command sets. Each command is described in following format: Print Command Function Format: ASCII: the standard ASCII character sequence Decimal: the decimal numbers sequence Hexadecimal: the hexadecimal number sequence Explanation: what the command does and how to use it.

  • Page 12: Character Print Commands

    ASCII： Decimal: Hexadecimal: Explanation: Set line spacing to n dot lines. n=0~255. One dot line is 1/203 inch for SP-POS58III, this command sets the dot-line spacing to n/203 inch. Default n=30. Example: n=30, 30 dot spacing (30/203 inch) 3.2.3 Character Print Commands ESC ！...
  • Page 13 SPRT ESC DC4 Cancel Double Width Character Print Format: ASCII: Decimal: Hexadecimal: Explanation: After carrying out this command, the characters will be printed in normal width. ESC % Select/Cancel User-defined Characters Format: ASCII: ％ Decimal: Hexadecimal: Explanation: When n=1, select user-defined character set; When n=0, select internal character set.

  • Page 14: Special Control Commands

    SPRT 3.2.4 Special Control Commands ESC c 5 Enable/Disable Switch Button Function Format: ASCII： Decimal: Hexadecimal: 1B Explanation: When n=1, button【LF】is enabled; When n=0, button【FEED】is disabled; Default n=0. 3.2.5 Graphics Print Commands ESC * Set Bit-map Graphics Format: ASCII： [d]k...
  • Page 15 SPRT 8-dot single 68DPI 101DPI density 8-dot double 68DPI 203DPI density 24-dot single 203DPI 101DPI density 24-dot double 203DPI 203DPI density GS / Print Download Bit-map Graphics Format: ASCII： ／ Decimal: Hexadecimal: Explanation: This command is used to print download bit-map graphics. n=0～3 ◆...

  • Page 16: Bar Code Print

    SPRT Horizontal Bit-map mode Vertical density density Normal 203DPI 203DPI Double width 203DPI 101DPI Double height 101DPI 203DPI Double height 101DPI 101DPI and double width GS * Define download bit-map graphics Format: ASCII： [d]k Decimal: [d]k Hexadecimal: 1D [d]k Explanation: This command is used to define download bit-map graphics.
  • Page 17 SPRT Decimal: 87 n1 Hexadecimal: 1D Explanation: n1: bar code narrow bar width, unit: dot. Each dot for SP-POS58III printer is 1/203 inch or 0.125mm. Default n1=3. n2: bar code broad bar width GS k Print bar code Format: ASCII：...

  • Page 18: Other Commands

    When n is different, the width of bar code will be different, as shows in the following tab: Narrow size Broad size Its unit is dot. Each dot for SP-POS58III is 1/203 inch or 0.125mm. Default n=3. 3.2.7 Other Commands ESC @ Initialize printer Format: ASCII：...
  • Page 19 SPRT ESC v Transmit Status of Printer Format: ASCII ： Decimal: Hexadecimal: Explanation: Send printer status to the host. When printer received the command, it transfers one byte through TXD serial interface. Definition of said byte is shown as below:...

  • Page 20: Appendix 1 Index Of Print Commands

    SPRT Undefined －－－ －－－ Undefined －－－ －－－ Appendix 1 Index of Print Commands Command name Command Description Print commands Print and feed line ESCJ Print and feed n dot lines Line spacing setting Set character line spacing to ESC2 commands...

  • Page 21: Appendix 2 Index Of Print Characters

    SPRT Appendix 2 Index of Print Characters ２０...
