CAPA840/843 Capa Board
Chapter 1
Introduction
® TM
The CAPA840, a 3.5" board, supports Intel Atom E3845/E3827 processors. Meanwhile
® ®
CAPA843, a 3.5' board, supports Intel Celeron J1900 processors. Both of them deliver
outstanding system performance through high-bandwidth interfaces, multiple I/O functions for
interactive applications and various embedded computing solutions.
The CAPA840/843 have two 204-pin unbuffered SO-DIMM sockets for dual channel DDR3L
1333/1066MHz memory with maximum capacity up to 8GB. There are two Gigabit/Fast
Ethernet ports, one SATA port with transfer rate up to 3Gb/s, one USB 3.0 super speed and
four USB 2.0 high speed compliant, and built-in HD audio codec that can achieve the best
stability and reliability for industrial applications. Additionally, it provides you with unique
embedded features, such as two serial ports (one RS-232/422/485 and one RS-232) and 3.5"
form factor that applies an extensive array of PC peripherals.
Introduction 1
